RHI-3630V-R(630W)

製品種別 電源 (Zippy)
電源の種類 N+1 Redundant
製品説明

製品仕様

wattage 630W
solution Server ,Workstation ,IPC
dimension_mm 140x150x83
dimension_inch 5.51x5.91x3.27
input_spec VOLTAGE: 90~264 VAC FULL RANGE INRUSH CURRENT: 20/40 amps @115/230 VAC (at 25 degrees ambient cold start for each power unit) PFC: Up to the target of 95% @115/230VAC, full load Efficiency: The maximum power supply system efficiency shall be 84.8%, measured at nominal input voltage 230 V and full loading
dc_output Output VoltageOutput Current Min.Output Current Max.Regulation LoadRegulation LineOutput Ripple & Noise Max.[P-P]+5V175+6/-2%±1%50mV+12V120±5%±1% 120mV +5VSB0.13.5±5%±1%50mV
features *TEMPERATURE RANGE : OPERATING 0℃ ~ 50℃, STORAGE –20℃ ~ 80℃
* HUMIDITY:OPERATING: 20%~80%, NON-OPERATING:10%~90%
* PROTECTION: OPP/OVP/OCP/SCP
* EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
* SAFETY: UL 60950/CUL CSA 22.2 No.60950/TUV EN-60950/CCC
* LEAKAGE CURRENT: Less than 3.5mA rms. Measurement will be made at 240 VAC and 60Hz.

*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
pdf MTBF(RoHS):http://www.zippy.com.tw//backend/DownLoad/DownLoad/Power/MTBF/RHI-3630V-R(RoHS).pdf
