G1W-2AE0G2(1500W)
| 製品種別 | 電源 (Zippy) |
|---|---|
| 電源の種類 | N+1 Redundant |
| 製品説明 |
製品仕様
| wattage | 1500W |
|---|---|
| solution | Server ,Workstation ,Storage System ,IPC |
| dimension_mm | 265.3x98.4x40 |
| dimension_inch | 10.44x3.87x1.57 |
| input_spec | VOLTAGE： 104～264VAC FULL RANGEFREQUENCY： 47～63HZINPUT CURRENT: 15A (RMS) FOR 115V / 10.5A (RMS) FOR 230VINRUSH CURRENT (PER POWER MODULE)：40/80 AMPS@115/230 VAC (at 25 degrees ambient cold start for each power unit)PFC: Up to the target of 95% @115/230VAC, full load |
| dc_output |
|
| features | * TEMPERATURE RANGE：OPERATING 0℃～40℃, STORAGE -20℃~80℃ * EFFICIENCY：SHALL BE 86% AT 230V AND FULL LOADING * OVER POWER PROTECITON: 110~160% * OVER VOLTAGE PROTECTION * REMOTE ON/OFF CONTROL * EMI NOISE FILTER: FCC CLASS B , CISPR 22 CLASS B * MEET IEC 61000-3-2 CLASS D (ACTIVE PFC) * SAFETY：TO MEET UL, CUL, TUV, CCC *THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS. |
| MTBF(RoHS):http://www.zippy.com.tw//backend/DownLoad/DownLoad/Power/MTBF/G1W-2AE0G2(RoHS).pdf DRAWING:http://www.zippy.com.tw//backend/DownLoad/DownLoad/Power/DRAWING/G1WGMA00.pdf |
