製品情報

BMTW3-5F00V3V(1500W)

製品種別 電源 (Zippy)
電源の種類 2U Redundant
製品説明

製品仕様

wattage 1500W
solution Server ,Workstation ,Storage System
dimension_mm 300x101x125
dimension_inch 11.81x3.98x4.92
input_spec VOLTAGE: 18~36VDC, NOMAL 24VDC STEADY-STATE CURRENT: 135/63 AMPS MAX AT ANY LOW/HIGH RANGE INPUT VOLTAGE INRUSH CURRENT: 50 AMPS @ 24VDC (at 25 degrees ambient cold start for each power unit)
dc_output
Output Voltage Output Current Min. Output Current Max. Regulation Load Regulation Line Output Ripple & Noise Max.[P-P]
+5V 0.5 60 ±5% ±50mV 50mV
+12 2 125 ±5% ±50mV 120mV
-12V 0 1.2 ±5% ±50mV 120mV
+3.3V 0.5 68 ±5% ±50mV 50mV
+5VSB 0.1 5 ±5% ±50mV 50mV
* +5V AND +3.3V TOTAL OUTPUT MAX: 524W
* TOTAL OUTPUT MAX: 1500W


features * TEMPERATURE RANGE: OPERATING 0℃ ~ 40℃,STORAGE -20℃ ~ 80℃
* HOLD UP TIME: When power shutdown DC output 5V must be maintain 1msec in regulation limit at normal input voltage
* EFFICIENCY: TYPICAL >80% @ 24VDC, 30~100% MAX LOAD
* POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms
* OUTPUT PROTECTION: OPP / OVP / SCP / OCP
* BALANCE LOAD SHARING DESIGN
* REMOTE ON/OFF CONTROL
* WARNING METHOD: AUDIO ALARM, FAULT LED, TTL
* SAFETY APPROVAL: UL, CUL, TUV, CCC


* THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
