H270-T71 (rev. 110)
| 製品種別 | サーバ |
|---|---|
| CPUソケット数 | |
| CPU | |
| 筐体サイズ | |
| 最大GPU数 | |
| 電源仕様 | |
| 用途/特長 | |
| 製品説明 |
製品仕様
| Dimensions (WxHxD, mm) | 2U 447 x 87.2 x 780 (mm) |
|---|---|
| Motherboard | MT70-HD2 |
| CPU | Per node: 2 x Marvell® ThunderX® ARM processors 64bit ARMv8 architecture 32 cores per processor, 1.8GHz BGA 2601, 28nm technology Total: 8 x Marvell® ThunderX® ARM processors Total 256 cores |
| Chipset | - |
| Memory | Per node: 16 x DIMM slots DDR4 memory supported only Quad channel memory architecture Up to total 512GB memory capacity 1866 MHz with 2DPC for Single Rank or Dual Rank RDIMMs / ECC UDIMMs 2133 MHz with 1DPC for Single Rank or Dual Rank RDIMMs / ECC UDIMMs NOTE: Due to processor specification, at least 4 x DIMM modules must be installed for one node Total: 64 x DIMM slots Up to total 2TB memory capacity |
| LAN | Per node: 2 x 40GbE QSFP+ LAN ports 1 x 10/100/1000 management LAN port Total: 8 x 40GbE QSFP+ LAN ports 4 x 10/100/1000 management LAN ports |
| Video | Integrated in Aspeed® AST2400 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp |
| Audio | - |
| Storage | Per node: 4 x 2.5" hot-swappable HDD/SSD bays Total: 16 x 2.5" hot-swappable HDD/SSD bays - NOTE: GIGABYTE recommends that you follow the QVL when selecting hard drives, to avoid any system compatibility issues |
| SAS | - |
| RAID | Depends on OS RAID |
| Peripheral Drives | - |
| Expansion Slots | Per node: 1 x Half-length low-profile slot with PCIe x16 (Gen3 x8 bus) connector 1 x Mezzanine PCIe x8 (Gen3 x8 bus) connector Total: 4 x Half-length low-profile slots with PCIe x16 (Gen3 x8 bus) connectors 4 x Mezzanine PCIe x8 (Gen3 x8 bus) connectors |
| Internal I/O | Per node: 2 x 18-pin power connectors 4 x SATA III 6Gb/s ports (1 with SATA DOM supported) 1 x SATA SGPIO header 1 x SATA DOM header 1 x USB 3.0 header 1 x COM2 header 1 x Case open connector 1 x PMBUS connector 1 x Clear CMOS header 1 x IPMB connector |
| Front I/O | Per node: 2 x USB 3.0 1 x VGA 1 x Power button with LED 1 x ID button with LED Total: 8 x USB 3.0 4 x VGA 4 x Power buttons with LED 4 x ID buttons with LED |
| Rear I/O | Per node: 2 x USB 3.0 1 x VGA 1 x COM1 2 x QSFP+ 1 x RJ45 1 x Power button with LED 1 x ID button with LED 1 x System reset button 1 x System status LED 2 x LAN activity LEDs 2 x LAN link status LEDs Total: 8 x USB 3.0 4 x VGA 4 x COM1 8 x QSFP+ 4 x RJ45 4 x Power button with LED 4 x ID button with LED 4 x System reset button 4 x System status LED 8 x LAN activity LEDs 8 x LAN link status LEDs |
| Backplane I/O | Speed and bandwidth: SATA 6Gb/s |
| TPM | - |
| Power Supply | 2 x 1600W redundant PSU 80 PLUS Platinum 100~230V AC |
| System Management | Aspeed® AST2400 management controller Avocent® MergePoint IPMI 2.0 web interface:
|
| OS Compatibility | Certified OS Ubuntu 16.04.1 64bit SLES12 SP2 Compatible OS openSUSE Tumbleweed openSUSE Leap 42.1+ RHEL 7.3 64bit CentOS 7.3 64bit |
| Weight | 38kg |
| System Fans | 16 x 40x40x56mm (23’000rpm) |
| Operating Properties | Operating temperature: 10°C to 35°C Operating humidity: 8-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) |
| Packaging Dimensions | 1133 x 724 x 261 (mm) |
| Packaging Content | - 1 x H270-T71 system - 1 x Quick Installation Guide - Rail kit |
| Part Numbers | Rackmount: 6NH270T71MR-00 Motherboard: 9MT70HD2NR-00 Power supply: 25EP0-216004-D0S Rail Kit: 25HB2-A86100-K0R |
