| Dimensions (WxHxD, mm) |
2U
448 x 87 x 755 |
| Motherboard |
MH60-RE1 |
| CPU |
Intel® Xeon® E5-2600 V3 processors
Intel® Xeon® E5-2600 V4 processorsNOTE: If only 1 CPU is installed, some PCIe, memory, I/O functions might be unavailable. |
| Socket |
Per node:
2 x LGA 2011-3Total:
8 x LGA 2011-3
Mounting pitch: square ILM (80x80mm)Max. length of M4 screw threads: 3.7mmScrews longer than 3.7mm might damage the motherboard |
| Chipset |
Intel® C612 |
| Memory |
Per node:
16 x DIMM slotsTotal:
64 x DIMM slotsDDR4 memory supported only
Quad channel memory architecture
RDIMM modules up to 32GB supported
LRDIMM modules up to 64GB supported
3DS LRDIMM modules up to 128GB supported
1.2V modules: 1600/1866/2133/2400 MHz |
| LAN |
Per node:
2 x 10Gb/s SFP+ LAN ports (Mellanox® ConnectX-3 Pro)
1 x GbE LAN ports (Intel® I210-AT)
1 x 10/100/1000 management LANTotal:
8 x 10Gb/s SFP+ LAN ports (Mellanox® ConnectX-3 Pro)
4 x GbE LAN ports (Intel® I210-AT)
4 x 10/100/1000 management LAN
1 x 10/100/1000 *CMC LAN
*CMC: Chassis Management Controller, to monitor all status of computing nodes. |
| Video |
Integrated in Aspeed® AST2400
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Management chip in CMC board:
Integrated in Aspeed® AST1050 |
| Audio |
- |
| Storage |
Per node:
4 x 2.5" SAS/SATA hot-swappable HDD/SSD bays ( from C612)
2 x 2.5" NVMe HDD/SSD baysTotal:
24 x 2.5" hot-swappable HDD/SSD bays
- 16 x SAS/SATA hot-swappable HDD/SSD bays ( from 4 x C612)
- 8 x NVMe HDD/SSD bays |
| RAID |
Intel® SATA RAID 0/1/5/10 |
| Peripheral Drives |
- |
| Expansion Slots |
Per node:
1 x Half-length low-profile slot with PCIe x16 (Gen3 x16 bus) connector
1 x Mezzanine PCIe x8 (Gen3 x8 bus) connectorTotal:
4 x Half-length low-profile slots with PCIe x16 (Gen3 x16 bus) connectors
4 x Mezzanine PCIe x8 (Gen3 x8 bus) connectors |
| Internal I/O |
Per node:
1 x COM header
1 x TPM header
1 x BMC SGPIO header
1 x JTAG BMC header
1 x PLD header
1 x PMBUS header
1 x PMBUS selection jumper
1 x BMC FRB jumper
1 x Clear CMOS jumper
1 x Power on selection jumper
1 x ACK selection jumper
1 x IPMB connector |
| Front I/O |
Per node:
1 x Power button with LED
1 x ID button with LED
1 x Status LEDTotal:
4 x Power button with LED
4 x ID button with LED
4 x Status LED
*1 x CMC status LED
*Only one CMC status LED per system |
| Rear I/O |
Per node:
2 x USB 3.0
1 x VGA
2 x SFP+
1 x RJ45
1 x RJ45 MLAN
1 x ID button with LEDTotal:
8 x USB 3.0
4 x VGA
8 x SFP+
4 x RJ45
4 x RJ45 MLAN
4 x ID button with LED
*1 x CMC MLAN
*Only one CMC MLAN per system |
| Backplane I/O |
- 16 x SAS/SATA ports
12Gb/s & 6Gb/s compatible
- 8 x NVMe ports for NVMe devices only |
| TPM |
1 x TPM header |
| Power Supply |
2 x 2000W redundant PSU
80 PLUS Platinum
AC input:
- 1000W: 100-127V/ 12-9.5A, 50-60Hz
- 1800W: 200-220V/ 10-9.5A, 50-60Hz
- 1980W: 220-230V/ 10-9.8A, 50-60Hz
- 2000W: 230-240V/ 10-9.8A, 50-60Hz
DC output:
Max 1000W@100-127V:
+12V/ 83.3A
+12Vsb/ 2.1A
1800W@200-220V
+12V/ 150.0A
+12Vsb/ 2.1A
1980W@220-230V
+12V/ 165.0A
+12Vsb/ 2.1A
2000W@200-240V
+12V/ 166.7A
+12Vsb/ 2.1A |
| System Management |
Aspeed® AST2400 management controller
Avocent® MergePoint IPMI 2.0 web interface:Cold Redundancy
Intelligent Power Management (IPM)
Network settings
Network security settings
Users control
Services settings
IPMI settings
Sessions control
LDAP settings
Power control
Voltages, fans and temperatures monitoring
System event log
Events management (platform events, trap settings, email settings)
Serial Over LAN
vKVM & vMedia (launch, configuration)
|
| OS Supported |
Windows Server 2008 R2 (x64)
Windows Server 2012 (x64)
Windows Server 2012 R2 (x64)
Red Hat Enterprise Linux 6.7 (x86/x64)
Red Hat Enterprise Linux 7.2 (x64)
SUSE Linux Enterprise Server 11.4 (x86/x64)
SUSE Linux Enterprise Server 12 (x64)
Ubuntu 12.04 LTS (x86/x64)
Ubuntu 14.04 LTS (x86/x64)
VMware ESXi 5.1 U2
VMware ESXi 5.5 U2
VMware ESXi 6.0 U1 |
| Weight |
25 kg (full packaging) |
| System Fans |
4 x 80x80x38mm (16’300rpm) |
| Operating Properties |
Operating temperature: 5°C to 35°C
Non-operating temperature: 0°C to 40°C
10-80% operating humidity at 30°C |
| Part Numbers |
- Barebone: 6NH23NH60MR-00
- Power Supply: 25EP0-220003-C2S
- Tool-less rail kit: 25HB2-AN6805-K0R |
| Packaging Dimensions |
981 X 585 X 314 mm |
| Packaging Content |
1 x H23N-H60
8 x CPU heatsinks
1 x Quick start guide
1 x Rail Kit |
