| Dimension |
180 x 119 x 30 mm (WxDxH) |
| Motherboard |
MIOPS2-SI |
| CPU |
Intel® Core™ i5-4300U
1.9GHz - 2.9GHz
2 cores 4 threads
3MB L2 cache
15W TDP |
| Socket |
1 x BGA 1168 |
| Memory |
2 x SO-DIMM DDR3L slots
Up to 16GB
1.35V 1600/1333MHz |
| LAN |
1 x GbE LAN port (Intel® I218-LM) |
| Video |
Intel® HD Graphics 4400
Max. resolution 3840x2160 @30Hz |
| Audio |
Realtek® ALC887 controller
Supports 2/4/5.1/7.1 channel configurations |
| Storage |
1 x 2.5" HDD/SSD bay, SATA III 6Gb/s |
| SATA |
1 x SATA III 6Gb/s port |
| Expansion Slots |
1 x mSATA slot
1 x Full-size Mini-PCIe slot |
| Rear I/O |
1 x 80-pin JAE TX25 OPS connector |
| Front I/O |
2 x WiFi antenna slots
1 x RJ45
2 x USB 3.0
1 x DisplayPort
1 x Power button
1 x Reset button
1 x Mic-In
1 x Line-Out |
| TPM |
TPM module onboard
Infineon® SLB9635TT1.2 controller |
| Power Supply |
Power delivery through 80-pin JAE TX25 OPS connector |
| OS Supported |
Windows Embedded 7
Windows 7 64bit
Windows 8.1 64bit |
| Weight |
750g |
| Operating Properties |
Operating temperature: -10°C to 60°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| Packaging Content |
1 x Mini-PCIe card bracket with 2 x screws
1 x Mini-PCIe screw
2 x HDD screws |
| Ordering Information |
5 pieces carton:
- Includes WiFi card (AW-NB159H)
- 362x333x242mm
- 9BSIOPS2MS‐SI‐242
8 pieces carton:
- No WiFi card
- 588x319x214mm
- 6BSIOPS2NS‐SI‐231 |
