Dimension |
180 x 119 x 30 mm (WxDxH) |
Motherboard |
MIOPS3-SI |
CPU |
Intel® Core™ i7-4550U
1.5GHz - 3.0GHz
2 cores 4 threads
4MB L2 cache
15W TDP |
Socket |
1 x BGA 1168 |
Memory |
2 x SO-DIMM DDR3L slots
Up to 16GB
1.35V 1600/1333MHz |
LAN |
1 x GbE LAN port (Intel® I218-LM) |
Video |
Intel® HD Graphics 5000
Max. resolution 3840x2160 @30Hz |
Audio |
Realtek® ALC887 controller
Supports 2/4/5.1/7.1 channel configurations |
Storage |
1 x 2.5" HDD/SSD bay, SATA III 6Gb/s |
SATA |
1 x SATA III 6Gb/s port |
Expansion Slots |
1 x mSATA slot
1 x Half-size Mini-PCIe slotPre-installed:
- 1 x WiFi + Bluetooth card
- Azurwave® AW-NB159H |
Rear I/O |
1 x 80-pin JAE TX25 OPS connector |
Front I/O |
2 x WiFi antenna slots
1 x RJ45
2 x USB 3.0
1 x DisplayPort
1 x Power button
1 x Reset button
1 x Mic-In
1 x Line-Out |
Internal I/O |
1 x SATA III 6Gb/s port
1 x LPC (80h) header
1 x USB 2.0 header
1 x SATA power connector
1 x Battery connector |
TPM |
TPM module onboard
Infineon® SLB9635TT1.2 controller |
Power Supply |
Power delivery through 80-pin JAE TX25 OPS connector |
OS Supported |
Windows Embedded 7
Windows 7 64bit
Windows 8.1 64bit |
Weight |
750g |
System Fans |
Active fan |
Operating Properties |
Operating temperature: -10°C to 60°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
Packaging Content |
1 x Mini-PCIe card bracket with 2 x screws
1 x Mini-PCIe screw
2 x HDD screws |
Ordering Information |
5 pieces carton:
- Includes WiFi card
- 362 x 333 x 242 mm
- 6BSIOPS3WMS-SI |
