| Dimension |
107.6(W) x 56.1(H) x 114.4(D) mm |
| Motherboard |
MZBAYAC
100 x 105 mm |
| CPU |
Intel® Atom™ processor E3825
Dual core, 22nm
1.33GHz
1MB cache
6W TDP |
| Socket |
1 x BGA 1170 |
| Flash Memory |
32GB of eMMC memory |
| Memory |
1 x SO-DIMM slot
1.35V DDR3L memory
Up to 8GB
1067MhzPre-installed:
- 1 x Crucial® CT25664BF160B
- 2GB
- 1600MHz |
| LAN |
2 x GbE LAN ports (Realtek RTL8111G) |
| Video |
Intel® HD graphics
Max. resolution via HDMI: 1920x1080 @ 60Hz
Max. resolution via VGA: 2560x1600 @60Hz |
| Audio |
Realtek® ALC283 |
| Storage |
1 x 2.5" HDD/SSD internal bay
Supports 7.0 & 9.5 mm HDD/SSD |
| SATA |
1 x SATA II 3Gb/s port |
| Expansion Slots |
1 x Half-size Mini-PCIe slotPre-installed:
- 1 x WiFi + Bluetooth card
- Azurewave® AW-NB159H |
| Front I/O |
1 x USB 3.0
1 x USB 2.0
1 x MicroSD card slot |
| Rear I/O |
1 x HDMI 1.4a
2 x RJ45
1 x DC-In
1 x Kensington lock slot |
| Side I/O |
1 x VGA
1 x Serial
1 x Headphone / MIC jack |
| Internal I/O |
1 x SATA II 3Gb/s port
1 x LPC (80h) header
1 x USB 2.0 header
1 x TPM header
1 x SATA power connector
1 x Battery connector |
| TPM |
1 x TPM header |
| Power Supply |
AC 100~240V
12V DC-In
36W/2.5A |
| OS Supported |
Windows 7 32bit / 64bit
Windows 8.1 32bit / 64bit |
| Weight |
400g |
| System Fans |
Fanless |
| Operating Properties |
Operating temperature: 0°C to 35°C
Operating humidity: 0%-85% (non-condensing)
Non-operating temperature: -20°C to 60°C
Non-operating humidity: 0%-85% (non-condensing) |
| Packaging Content |
1 x Crucial® CT25664BF160B
1 x Azurewave® AW-NB159H
1 x Quick starting guide
1 x Mini-PCIe card bracket
1 x VESA mount bracket
1 x Power plug adapter (US)
1 x 36W power adapter |
| Ordering Information |
10 pieces carton: 9BKMA1WMR-00
Packaging dimensions: 411 x 383 x 200mm |
