| Dimensions (WxHxD, mm) |
2U
448 x 87.5 x 800 |
| Motherboard |
MG50-G21 |
| CPU |
Intel® Xeon® E5-2600 V3 processorsNOTE: If only 1 CPU is installed, some PCIe, memory, network or I/O functions might be unavailable. |
| Socket |
2 x LGA 2011-3
Mounting pitch: narrow ILM (56x94mm)Max. length of M4 screw threads: 3.7mmScrews longer than 3.7mm might damage the motherboard |
| Chipset |
Intel® C612 |
| Memory |
24 x DIMM slotsDDR4 memory supported only
Quad channel memory architecture
ECC RDIMM / LRDIMM modules supported
Single and dual rank RDIMM modules up to 32GB supported
Quad rank LRDIMM modules up to 64GB supported
1.2V modules: 1600/1866/2133 MHz |
| LAN |
2 x GbE LAN ports (Intel® I350-AM2)
1 x 10/100/1000 management LAN
2 x QSFP+ ports (supporting 56Gb/s FDR InfiniBand or 40GbE) card (Mellanox® MT27508A1-FCCR-FV) in option (GC-MNXE2)
2 x 10Gb/s SFP+ LAN card (Mellanox® MT27518A1-FCCR-XE) in option (GC-MNXE20) |
| Video |
Integrated in Aspeed® AST2400
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp |
| Storage |
8 x 2.5" hot-swappable HDD/SSD bays |
| SAS |
GC-MSLZ1 expansion card in option:
2 x Mini-SAS (for 8 x SAS 6Gb/s ports)
LSI® SAS2208 controller
Hardware RAID 0/1/5/6/10/50/60
Hardware RAID 5/6 XOR Engine (single pass)
Low profile PCIe 2.0 x8 mezzanine connector
76.8 x 98 mm
|
| SATA |
10 x SATA III 6Gb/s ports |
| RAID |
Intel® SATA RAID 0/1/5/10 |
| Peripheral Drives |
- |
| Expansion Slots |
8 x PCIe x16 (Gen3 x16 bus) connectors supporting:
Intel® Xeon Phi cards
NVIDIA® cards
AMD® cards
Please contact us for details about the supported card models
1 x Half-length low-profile slot
1 x PCIe x16 (Gen3 x8 bus) connector
1 x Proprietary PCIe x8 (Gen3 x8 bus) mezzanine connector |
| Front I/O |
1 x Power button with LED
1 x ID button with LED
2 x LAN activity LEDs
1 x HDD activity LED
1 x System status LED
1 x Reset button |
| Rear I/O |
2 x USB 3.0
1 x VGA
1 x Serial
3 x RJ45
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
4 x LAN activity LED |
| Internal I/O |
1 x 18-pin power connector
1 x 14-pin power connector
2 x 8-pin power connectors
2 x 4-pin power connectors
10 x SATA III 6Gb/s ports
1 x USB 3.0 header
1 x USB 2.0 header
1 x TPM header
1 x HDD back plane board header
1 x 12-pin front panel header
1 x 23-pin front panel header
1 x JTAG header
2 x SATA SGPIO headers
1 x Front VGA header
1 x Serial header
1 x IPMB connector
1 x P12V standby connector
1 x PMBus selection jumper
1 x Clear CMOS jumper
1 x LT debug jumper |
| Backplane I/O |
8 x SAS/SATA 6Gb/s ports |
| TPM |
1 x TPM header |
| Power Supply |
2 x 1600W redundant PSU
80 PLUS Platinum
AC input:
- 100-127V/ 12.9A, 47-63Hz
- 200-240V/9.5A, 47-63Hz
DC output:
- 1000W@100-127V
- 1600W@200-240V |
| System Management |
Aspeed® AST2400 management controller
Avocent® MergePoint IPMI 2.0 web interface:Network settings
Network security settings
Users control
Services settings
IPMI settings
Sessions control
LDAP settings
Power control
Voltages, fans and temperatures monitoring
System event log
Events management (platform events, trap settings, email settings)
Serial Over LAN
vKVM & vMedia (launch, configuration)
|
| OS Supported |
Windows Server 2008 R2 (x64)
Windows Server 2012 (x64)
Windows Server 2012 R2 (x64)
Red Hat Enterprise Linux 6.5 (x64)
Red Hat Enterprise Linux 6.6 (x64)
Red Hat Enterprise Linux 7.0 (x64)
SUSE Linux Enterprise Server 11 SP3 (x64)
SUSE Linux Enterprise Server 12 (x64)
VMware ESXi 5.1 U2
VMware ESXi 5.5 U2
VMware ESXi 6.0 |
| Weight |
23.5 kg |
| System Fans |
8 x 80x80x38mm (15000rpm) |
| Operating Properties |
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing) |
| Part Numbers |
Barebone with rail kit: 6NG250G50MR-00
Rail kit: 25HB2-A86100-K0R |
| Packaging Content |
1 x Driver CD
2 x CPU heat sinks
1 x Rail Kit |
