| Form Factor |
Thin Mini-ITX
170W x 170D (mm) |
| Operating Properties |
Operating temperature: 0°C to 50°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-95% (non-condensing) |
| CPU |
Supports for Intel® Core™ i7 processors
Intel® Core™ i5 processors
Intel® Core™ i3 processors
Intel® Pentium® processors
Intel® Celeron® processors
L3 cache varies with CPU |
| Socket |
1 x LGA 1151 |
| Chipset |
Intel® H110 Express Chipset |
| Memory |
1 x SO-DIMM slot
1.2V DDR4 memory module supported
Up to 16GB
2133MHz |
| LAN |
1 x GbE LAN port (Realtek RTL8111HS-CG) |
| Video |
Intel HD Graphics
Max. resolution via DP: 4096 x 2304 @ 60Hz
Max. resolution via HDMI: 4096 x 2160 @ 24Hz
Max. resolution via LVDS: 1920 x 1200 @ 60Hz |
| Audio |
Realtek ALC887 |
| SATA |
2 x SATA 6Gb/s ports |
| RAID |
- |
| Expansion Slots |
1 x M.2 slot:
- M-key
- SATA 6Gb/s
- Supports NGFF-2260/2280 cards
1 x M.2 slot:
- E-key
- PCIe 2.0 x1 signal
- Supports NGFF-2230 cards |
| Internal I/O |
1 x 12V power connector
3 x SATA 6Gb/s ports
1 x SATA power connector
1 x LVDS 18/24bit connector
1 x CPU fan header
1 x System fan header
3 x USB 2.0 headers (up to 5 x USB 2.0 ports)
1 x Front panel header
1 x Front audio header
1 x Speaker header
1 x Digital microphone header
1 x Backlight switch header
1 x FPD header
1 x FPD power jumper
1 x LCD selection jumper
1 x Clear CMOS jumper
1 x TPM header |
| Rear I/O |
1 x DC-in
1 x RJ45
4 x USB 3.0
1 x DisplayPort (v1.2)
1 x HDMI (v1.4)
1 x Line-out
1 x MIC-in |
| TPM |
TPM header |
| OS Supported |
Windows 10 (x64)
Windows 8.1 (x64)
Windows 7 (x32/x64)
- Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7 |
| PSU Connectors |
1 x 12-19V DC-in or
1 x 12V power connector |
| Packaging Content |
1 x SATA power cable (370mm) (P/N: 25CRI-270320-D3R)
1 x 25.54mm I/O shield (P/N: 12AIO-MDH110-00R)
1 x 44.45mm I/O shield (P/N: 12AIO-MDH111-00R) |
| Ordering Information |
9MDH11JINR-SI
20 units per carton
Packaging dimensions: 550 x 451 x 330 mm |
