| Form Factor |
Thin Mini-ITX
170W x 170D (mm) |
| Operating Properties |
Operating temperature: -10°C to 50°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| CPU |
6th Gen. Intel Core Processors |
| Socket |
1 x LGA 1151 |
| Chipset |
Intel H110 |
| Memory |
2 x SO-DIMM slots
1.35V DDR3L memory only
Up to 32GB
1600MHz |
| LAN |
1 x GbE LAN port (Realtek RTL8111HS-CG) |
| Video |
Intel HD Graphics
Max. resolution via DP: 4096 x 2304 @ 60Hz
Max. resolution via HDMI: 4096 x 2160 @ 60Hz
Max. resolution via LVDS: 1920 x 1200 @ 60Hz |
| Audio |
Realtek ALC887 |
| SATA |
4 x SATA 6Gb/s ports
(3 x SATA 6Gb/s ports if the SATA M.2 slot is used) |
| RAID |
- |
| Expansion Slots |
1 x PCIe x4 (3.0 x4 bus) slot
1 x M.2 slot:
- M-key
- SATA 6Gb/s or PCIe 2.0 x4 signal
- Supports NGFF-2260/2280 cards
1 x M.2 slot:
- E-key
- PCIe 2.0 x1 signal
- Supports NGFF-2230 cards |
| Internal I/O |
1 x 12V power connector
4 x SATA 6Gb/s ports
1 x SATA power connector
1 x LVDS 18/24bit connector
1 x CPU fan header
1 x System fan header
3 x USB 2.0 headers (up to 5 x USB 2.0 ports)
1 x Front panel header
1 x Front audio header
1 x Digital microphone header
1 x Backlight switch header
1 x FPD header
1 x LCD selection jumper
1 x Clear CMOS jumper
1 x NFC connector
1 x Serial header |
| Rear I/O |
1 x DC-in
1 x RJ45
4 x USB 3.0
1 x DisplayPort v1.2
1 x HDMI v2.0
1 x Line-out
1 x MIC-in |
| TPM |
- |
| OS Supported |
Windows 10 (x64)
Windows 8.1 (x64)
Windows 8 (x64)
Windows 7 (x32/x64) |
| PSU Connectors |
1 x 12-19V DC-in or
1 x 12V power connector |
| Packaging Content |
1 x SATA power cable (710mm)
1 x 25.54mm I/O shield
1 x 44.45mm I/O shield |
| Ordering Information |
9MDH11HINR-SI
20 units per carton
Packaging dimensions: 550 x 451 x 330 mm |
