| Form Factor |
Thin Mini-ITX form factor
170 x 170 mm
6.7" x 6.7" |
| CPU |
BGA 559 socket
Intel® Atom™ D2550 (1.86GHz, dual core, BD support, 10W TDP) |
| Chipset |
Intel® NM10 chipset |
| Memory |
2 x SO-DIMM slots
Up to 8GB DDR3 memory
1333MHz |
| LAN |
1 x GbE LAN
Realtek RTL8111E |
| Video |
Intel® GMA3650
Supports DirectX 9 |
| Audio |
Realtek ALC887
Support High Definition Audio
Support speaker 2 Channel: 3W / 4ohm 2ch
Support 7.1 Channel Jack
|
| SATA |
2 x SATA II 3Gbs |
| RAID |
- |
| Expansion Slots |
1 x mSATA
1 x Mini-PCIe (half size) |
| Internal I/O |
2 x USB 2.0
2 x COM
1 x Front audio header
1 x System fan
1 x CPU fan
1 x Front panel header
1 x ATX DC In (4 Pin)
1 x ATX DC In (24 Pin) |
| Rear I/O |
4 x USB 2.0
1 x HDMI-Out
1 x SPDIF-Out
1 x Audio jack
1 x RJ45
1 x DC-In |
| Power Supply |
DC-In 19V |
