| Form Factor |
Proprietary
100(W) x 108.5(D) mm |
| Operating Properties |
Operating temperature: -10°C to 50°C
Operating humidity: 0%-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| CPU |
Intel Atom processor E3825
Dual core, 22nm
1.33GHz
1MB cache
6W TDP |
| Socket |
1 x BGA 1170 |
| Memory |
1 x SO-DIMM slot
DDR3L memory supported
Up to 8GB
1066Mhz |
| Flash Memory |
- |
| LAN |
1 x GbE LAN port (Realtek RTL8111G) |
| Video |
Intel HD Graphics |
| Audio |
Realtek ALC283 controller |
| SATA |
1 x SATA II 3Gb/s port |
| Expansion Slots |
1 x Half-size Mini-PCIe slot |
| Internal I/O |
1 x SATA II 3Gb/s port
1 x SATA power connector
1 x Battery connector
1 x GPIO connector
2 x Expansion card connectors |
| Rear I/O |
1 x RJ45
1 x HDMI v1.4
1 x USB 3.0
1 x USB 2.0
1 x DC-in
1 x VGA
1 x Line-out / MIC-in |
| TPM |
- |
| OS Supported |
Windows 7 (x32)
Windows 8.1 (x32) |
| PSU Connectors |
- |
| Power Supply |
AC 100~240V
12V DC-in |
| Packaging Content |
- |
| Ordering Information |
Bilk: 9MZBAYADNR-00
MoQ: 10 units
Box size: 311x258x199mm
Optional 30W adapter: 25EP2-500303-A3S |
