| Form Factor |
Mini-ITX
170W x 170D (mm) |
| CPU |
Intel® Atom™ Processor C2750
8 cores / 8 threads
2.4 - 2.6 GHz
4MB L2 cache
20W max. TDP |
| Socket |
1 x BGA 1283 |
| Chipset |
- |
| Memory |
4 x DIMM slots
Supports unbuffered ECC or non-ECC UDIMM modules
Supports single rank and dual rank UDIMM modules
Supports 1.35V and 1.5V modules
Up to 64GB
1600/1333MHz |
| LAN |
4 x GbE LAN ports (Intel® I354)
1 x 10/100 management LAN |
| Video |
Integrated in Aspeed® AST2400
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp |
| Audio |
- |
| SAS |
- |
| SATA |
2 x SATA III 6Gb/s ports
4 x SATA II 3Gb/s ports |
| RAID |
- |
| Expansion Slots |
1 x PCIe x16 (Gen2 x16 bus) slot |
| Internal I/O |
1 x 24-pin ATX main power connector
1 x 8-pin 12V auxiliary power connector
1 x CPU fan header
1 x System fan header
2 x SATA III 6Gb/s ports
4 x SATA II 3Gb/s ports
1 x CMOS battery
1 x HDD back plane board header
1 x LED header
1 x Skip supervisor password jumper
1 x Clear CMOS jumper
1 x BIOS recovery jumper
1 x BMC jumper
1 x PMBUS header
1 x JTAG header
1 x Front panel header
1 x Front panel header (proprietary)
1 x SATA port DOM support jumper
1 x IPMB connector
1 x TPM header
1 x LPC header |
| Rear I/O |
1 x Power button with LED
1 x ID button with LED
1 x Status LED
1 x Serial
1 x VGA
5 x RJ45
2 x USB 2.0 |
| TPM |
1 x TPM header |
| OS Supported |
Windows Server 2008 Enterprise R2 SP1 (x64)
Windows Server 2012 R2 (x64)
Red Hat Enterprise Linux 6.4 (x64)
SUSE Linux Enterprise Server 11.3 (x64) |
| Board Management |
Aspeed® AST2400 management controller
Avocent® MergePoint IPMI 2.0 web interface:Network settings
Network security settings
Users control
Services settings
IPMI settings
Sessions control
LDAP settings
Power control
Voltages, fans and temperatures monitoring
System event log
Events management (platform events, trap settings, email settings)
Serial Over LAN
vKVM & vMedia (launch, configuration)
|
| PSU Connectors |
1 x 24-pin ATX main power connector
1 x 8-pin 12V auxiliary power connector |
| Retail Packaging Content |
1 x Driver CD
1 x I/O shield
2 x SATA II 3Gb/s cables (500mm) |
| Reference Numbers |
Retail: 9M9SISLMR-00 |
