| Form Factor |
Mini-ITX
170W x 170D (mm) |
| Operating Properties |
Operating temperature: -10°C to 60°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| CPU |
Intel® Atom™ D525
2 cores / 4 threads
1.8 GHz
13W max. TDP |
| Socket |
1 x BGA 559 |
| Chipset |
Intel® ICH8M |
| Memory |
1 x SO-DIMM DDR3 slot
Single channel memory architecture
Up to 4GB
1.5V modules: 800 MHz |
| LAN |
2 x GbE LAN ports (Realtek® RTL8111E) |
| Video |
Intel® GMA3150 |
| Audio |
Realtek® ALC269 controller
Supports 2/4 channel configurations |
| SATA |
2 x SATA II 3Gb/s ports |
| RAID |
- |
| Expansion Slots |
1 x Full-size Mini-PCIe slot |
| Internal I/O |
3 x USB 2.0 headers
5 x Serial (RI/5V/12V) headers
1 x Front audio header
1 x LVDS 18bit
1 x System fan header
1 x CPU fan header
2 x SATA II 3Gb/s ports
2 x SATA power connectors
1 x Front panel header
1 x Back light control
1 x VGA header
1 x Keyboard + mouse header
1 x 4-pin 12V ATX power connector
1 x SMBus (co-lay with F_USB3) |
| Rear I/O |
4 x USB 2.0
1 x Serial (RS232/ RS422/ RS485)
1 x VGA
1 x PS/2
1 x RJ11 (for cash drawer)
1 x Line-Out
1 x LPT
2 x RJ45
1 x DC-In |
| TPM |
- |
| OS Supported |
Win XP
Win 7
Linux
POSReady 2009
POSReady 7 |
| PSU Connectors |
1 x 4-pin 12V ATX power connector |
| Power Supply |
1 x DC-In 12V |
| Ordering Information |
9MNIC8CINS-CC |
| Packaging Content |
- |
![](/admin/imgs/gigabyte/MNIC8CI.jpg?5.63511008004756")
