| Form Factor |
Mini-ITX
170W x 170D (mm) |
| Operating Properties |
Operating temperature: -10°C to 60°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| CPU |
Intel® Atom™ D2550
2 cores / 4 threads
1.86 GHz
10W max. TDP |
| Socket |
1 x BGA 559 |
| Chipset |
Intel® NM10 |
| Memory |
2 x SO-DIMM DDR3 slots
Single channel memory architecture
Up to 4GB
1.5V modules: 1066 MHz |
| LAN |
2 x GbE LAN ports (Realtek® RTL8111E) |
| Video |
Intel® GMA3650 |
| Audio |
Realtek® ALC887 controller
Supports 2/4/5.1/7.1 channel configurations |
| SATA |
2 x SATA II 3Gb/s ports |
| RAID |
- |
| Expansion Slots |
1 x PCIe x1 (Gen2 x1 bus) slot
1 x Half-size Mini-PCIe slot |
| Internal I/O |
1 x USB 2.0 header
2 x SATA II 3Gb/s ports
2 x Serial headers
1 x Front audio header
1 x System fan header
1 x CPU fan header
1 x Front panel header
1 x 4-pin 12V ATX power connector
1 x 24-pin ATX main power connector |
| Rear I/O |
4 x USB 2.0
1 x PS/2
1 x HMDI
1 x DisplayPort
1 x VGA
1 x MIC-In
1 x Line-Out
1 x Line-In
2 x RJ45 |
| TPM |
- |
| OS Supported |
Windows 7 (32/64bit) |
| PSU Connectors |
1 x 4-pin 12V ATX power connector
1 x 24-pin ATX main power connector |
| Power Supply |
- |
| Ordering Information |
9M5NM1AINR-SI |
| Packaging Content |
- |
![](/admin/imgs/gigabyte/M5NM1AI.jpg?1.93854111553268")
