| Form Factor |
Thin Mini-ITX
170W x 170D (mm) |
| Operating Properties |
Operating temperature: -10°C to 60°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| CPU |
AMD® Fusion™ APU A4-5/A6-5/A8-5/A10-5 |
| Socket |
1 x FM2 |
| Chipset |
AMD® A75 |
| Memory |
2 x SO-DIMM DDR3 slots
Dual channel memory architecture
Up to 16GB
1.5V modules: 1600/1866 MHz |
| LAN |
1 x GbE LAN port (Realtek®
RTL8111E) |
| Video |
AMD® HD7480D-HD7660D
1 x Onboard LVDS: max. resolution 1920x1080 32bit |
| Audio |
Realtek® ALC887 controller
Supports 2/4/5.1/7.1 channel configurations |
| SATA |
4 x SATA III 6Gb/s ports |
| RAID |
AMD® SATA RAID 0/1/10 |
| Expansion Slots |
1 x mSATA slot
1 x Half-size Mini-PCIe slot |
| Internal I/O |
1 x 2-pin ATX 19V power connector
3 x USB 2.0 headers
1 x Digital MIC header
1 x LVDS 18/ 24bit
1 x Front audio header
1 x System fan header
1 x CPU fan header
1 x SATA power (15-pin)
1 x Front panel header
1 x Back light control
1 x Speaker header
1 x Serial header (optional) |
| Rear I/O |
4 x USB 3.0
1 x DisplayPort (optional)
1 x HDMI
1 x MIC-In (optional)
1 x Line-Out
1 x RJ45
1 x DC-In |
| TPM |
- |
| OS Supported |
Windows 7 (32/64bit)
Windows 8 (32/64bit) |
| PSU Connectors |
1 x DC-In 12V/19V
1 x 2-pin ATX 19V power connector |
| Power Supply |
DC-In 19V or 12V
Adapters available in option:
120W, 19V, 6.3A, DC plug (74x51mm)
|
| Ordering Information |
9MQHUDVINR-SI |
| Packaging Content |
- |
