| Form Factor |
microATX
244W x 244D (mm) |
| Operating Properties |
Operating temperature: -10°C to 60°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| CPU |
Supports Intel® 2nd & 3rd Gen processors
Up to 77W TDP |
| Socket |
1 x LGA 1155 |
| Chipset |
Intel® H61 |
| Memory |
2 x DIMM DDR3 slots
Dual channel memory architecture
Up to 8GB
1.5V modules: 1333/1600 MHz |
| LAN |
1 x GbE LAN port (Realtek® RTL8111E) |
| Video |
Integrated graphics processor |
| Audio |
Realtek® ALC662 controller
Supports 2/4/5.1 channel configurations |
| SATA |
4 x SATA II 3Gb/s ports |
| RAID |
- |
| Expansion Slots |
1 x PCIe x16 (Gen3 x16 bus) slot
2 x PCIe x1 (Gen2 x1 bus) slots
1 x PCI |
| Internal I/O |
1 x 4-pin 12V ATX power connector
1 x 24-pin ATX main power connector
2 x Serial headers
1 x CPU fan header
1 x System fan header
1 x Front audio header
1 x LPC
2 x USB 2.0 headers |
| Rear I/O |
4 x USB 2.0
1 x P/S2
1 x VGA
1 x DVI-I
1 x LPT
1 x Audio jack
1 x RJ45 |
| TPM |
- |
| OS Supported |
Windows 7 32/64bit
Windows 8.1 32/64bit |
| PSU Connectors |
1 x 4-pin 12V ATX power connector
1 x 24-pin ATX main power connector |
| Power Supply |
- |
| Ordering Information |
9MSH61TWNR-SI |
| Packaging Content |
- |
