| Form Factor |
microATX
244W x 244D (mm) |
| Operating Properties |
Operating temperature: -10°C to 60°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| CPU |
Supports Intel® 2nd & 3rd Gen processors
Up to 77W TDP |
| Socket |
1 x LGA 1155 |
| Chipset |
Intel® H61 |
| Memory |
2 x SO-DIMM DDR3 slots
Dual channel memory architecture
Up to 8GB
1.5V modules: 1333/1600 MHz |
| LAN |
2 x GbE LAN ports (Realtek® RTL8111E) |
| Video |
Integrated graphics processor |
| Audio |
Realtek® ALC269 controller
Supports 2/4 channel configurations |
| SATA |
2 x SATA II 3Gb/s ports |
| RAID |
- |
| Expansion Slots |
1 x PCIe x16 (Gen3 x16 bus) slot
1 x PCIe x1 (Gen2 x1 bus) slot
2 x PCI
1 x Half-size Mini-PCIe
1 x Full-size Mini-PCIe |
| Internal I/O |
1 x 4-pin 12V ATX power connector
1 x 24-pin ATX main power connector
3 x USB 2.0 headers
8 x Serial headers
1 x CPU fan header
2 x System fan headers
1 x Front audio header
1 x Front panel header
1 x LPC
1 x LPT
1 x LVDS 18/24bit
1 x GPIO 8bit
1 x Speaker header |
| Rear I/O |
4 x USB 2.0
2 x Serial
1 x VGA
1 x DVI-I
1 x P/S2
1 x Audio jack
2 x RJ45 |
| TPM |
TPM module onboard
Infineon® SLB9635TT1.2 controller |
| OS Supported |
Windows XP 32/64bit
Windows 7 32/64bit
Windows 8.1 32/64bit |
| PSU Connectors |
1 x 24-pin ATX main power connector
1 x 4-pin ATX DC-in auxiliary power connector |
| Power Supply |
- |
| Ordering Information |
9MATMH61MR-SI |
| Packaging Content |
1 x Driver CD
1 x I/O shield |
