| Form Factor |
microATX
244W x 244D (mm) |
| Operating Properties |
Operating temperature: -10°C to 60°C
Operating humidity: 0-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| CPU |
4th Gen. Intel Core Processors
Up to 85W TDP |
| Socket |
1 x LGA 1150 |
| Chipset |
Intel H81 |
| Memory |
2 x SO-DIMM slots
1.5V Dual channel DDR3 memory
Up to 16GB
1333/1600MHz |
| LAN |
2 x GbE LAN ports (Realtek RTL8111G) |
| Video |
Intel HD Graphics
Max. resolution via DVI: 1920 x 1200
Max. resolution via D-Sub: 1920 x 1200
Max. resolution via LVDS: 1920 x 1080 |
| Audio |
Realtek ALC269 controller
Supports 2/4 channel configurations |
| SATA |
2 x SATA 3Gb/s ports |
| Expansion Slots |
1 x PCIe x16 (3.0 x16 bus) slot
1 x PCIe x1 (2.0 x1 bus) slot
2 x PCI
1 x Half-size mini-PCIe
1 x Full-size mini-PCIe |
| Internal I/O |
1 x ATX power connector
1 x 12V power connector
3 x USB 2.0 headers
2 x SATA 3Gb/s ports
8 x Serial headers
1 x CPU fan header
1 x System fan header
1 x Front audio header
1 x Front panel header
1 x LPC
1 x LPT
1 x LVDS 18bit
1 x Speaker header |
| Rear I/O |
2 x RJ45
4 x USB 3.0
2 x Serial
1 x D-Sub
1 x DVI-I
1 x P/S2
1 x Audio jack |
| TPM |
Infineon SLB9635TT1.2 controller |
| OS Supported |
Windows 8.1 (x32/x64)
Windows 7 (x32/x64) |
| PSU Connectors |
1 x 24-pin ATX power connector
1 x 4-pin 12V ATX auxiliary power connector |
| Ordering Information |
9MATMH81MR-SI |
| Packaging Content |
- |
![](/admin/imgs/gigabyte/MATMH81.jpg?7.44228615033538")
