| Form Factor |
Proprietary
100(W) x 108.5(D) mm |
| CPU |
Intel® Atom™ processor E3815
Single core, 22nm
1.46GHz
512KB cache
5W TDP |
| Socket |
1 x BGA 1170 |
| Chipset |
- |
| Memory |
1 x SO-DIMM slot
DDR3L ECC memory supported
Up to 8GB
1066Mhz |
| Flash Memory |
4GB of eMMC memory |
| LAN |
1 x GbE LAN port (Realtek® RTL8111G) |
| Video |
Intel® HD Graphics |
| Audio |
- |
| SAS |
- |
| SATA |
1 x SATA II 3Gb/s port |
| RAID |
- |
| Expansion Slots |
1 x Full-size Mini-PCIe slot |
| Internal I/O |
1 x RTC header
1 x System fan header
1 x LPC (80h) header
1 x LVDS connector
1 x USB 2.0 header
1 x SATA power connector
1 x System power connector |
| Rear I/O |
1 x RJ45
1 x USB 3.0
1 x USB 2.0
1 x DC-In
1 x MicroSD card slot
1 x Serial
1 x HDMI-Out |
| TPM |
- |
| OS Supported |
Windows 7 (x32/x64)
Windows 8.1 (x32/x64)
Android 4.4
Fedora 20 |
| PSU Connectors |
- |
| Power Supply |
AC 100~240V
12V DC-In |
| Operating Properties |
Operating temperature: -10°C to 50°C
Operating humidity: 0%-85% (non-condensing)
Non-operating temperature: -40°C to 70°C
Non-operating humidity: 0%-85% (non-condensing) |
| Ordering Information |
Bulk: 9MZBAYVPNR-SI
MoQ: 10 units
Box dimensions: 411x383x200mm
Optional 30W/12V power adapter: 25EP2-500303-A3S |
| Packaging Content |
1 x Mini-PCIe card bracket
2 x M2x4L H=0.8 screws |
