| Form Factor |
CEB (12” x 10.5”) |
| CPU |
Dual Intel Xeon processor 5500/ 5600 series |
| Chipset |
Intel 5500 chipset with Intel ICH10R |
| Memory |
6 DDR3 DIMM sockets support registered or ECC unbuffered
6 channel native 1066/ 1333MHz |
| LAN |
2 Gigabit LAN (Intel 82567LM + Intel 82574L) |
| Video |
XGI Volari Z9s 32MB DDR2 |
| SATA |
6 ports SATA 3Gbps via Intel ICH10R |
| RAID |
Intel SW RAID 0/ 1/ 5/ 10
Optional 8 ports SAS 6Gbps HW RAID add-on card: GC-RLE087-RH
Optional 8 ports SAS 6Gbps SW RAID add-on card: GC-RLE086-RH |
| Expansion Slots |
1 PCI Express 2.0 x16
2 PCI Express 2.0 x4 (x8 mechanical)
1 PCI Express 1.0 x4 (x8 mechanical)
1 PCI |
| Board Management |
Hardware Monitor |
| Reference Numbers |
9M7TCSV10R-00 |
