| Form Factor |
SSI EEB (12” x 13”) |
| CPU |
Dual Intel Xeon processor 5500/ 5600 series |
| Chipset |
Intel 5520 chipset with Intel ICH10R |
| Memory |
12 DDR3 DIMM sockets support registered or ECC unbuffered
6 channel native 1066/ 1333MHz |
| LAN |
2 Gigabit LAN (Intel 82567LM + Intel 82574L) |
| Audio |
7.1+2 channel HD audio (Realtek ALC889A) |
| SATA |
6 ports SATA 3Gbps via Intel ICH10R |
| RAID |
Intel SW RAID 0/ 1/ 5/ 10
Optional 8 ports SAS 6Gbps HW RAID add-on card: GC-RLD087-RH/ GC-RLE087-RH
Optional 8 ports SAS 6Gbps SW RAID add-on card: FC-RLD086-RH/ GC-RLE086-RH |
| Expansion Slots |
1 PCI Express 2.0 x16
2 PCI Express 2.0 x4 (x8 mechanical)
1 PCI Express 1.0 x4 (x8 mechanical)
1 PCI
1 SO-DIMM IF |
| Reference Numbers |
9M7TEWH1NR-DY |
