| Form Factor |
microATX
244W x 244D (mm) |
| CPU |
Supports Intel® Xeon® processor E3-1200 V3 product family
Supports 4th gen Intel® Core™ i3 processors |
| Socket |
1 x LGA 1150 |
| Chipset |
Intel® C222 |
| Memory |
4 x DIMM slots
Supports ECC UDIMM modules only
Supports single rank and dual rank UDIMM modules
Up to 32GB
1333/1600/(1866*) MHz*Supported by Intel® Xeon® E3-1200 V4 processors only |
| LAN |
2 x GbE LAN ports (Intel® I210-AT) |
| Video |
Integrated in Aspeed® AST1300
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp |
| Audio |
- |
| SAS |
- |
| SATA |
2 x SATA III 6Gb/s ports
4 x SATA II 3Gb/s ports |
| RAID |
Intel® SATA RAID 0/1/10/5 |
| Expansion Slots |
1 x PCIe x16 (Gen3 x16 bus) slot
1 x PCIe x8 (Gen2 x4 bus) slot
1 x PCIe x4 (Gen2 x1 bus) slot |
| Internal I/O |
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
4 x System fan headers
1 x PMBus connector
1 x IPMB connector
1 x SATA SGPIO header
1 x Clearing supervisor password jumper
1 x ME recovery jumper
1 x BIOS Recovery jumper
1 x Clear CMOS jumper
1 x CMOS battery
4 x SATA II 3Gb/s ports
2 x SATA III 6Gb/s ports
1 x SATA port 1 DOM support jumper
1 x SATA port 0 DOM support jumper
2 x USB 2.0 Type A connector
1 x USB 3.0 header
1 x ME update jumper
1 x Front panel header
1 x Back plane board header
1 x TPM header
1 x Serial header
1 x Case open intrusion header |
| Rear I/O |
4 x USB 2.0
1 x Serial
1 x VGA
2 x RJ45 |
| TPM |
1 x TPM header |
| OS Supported |
Windows Server 2008 (x86/x64)
Windows Server 2008 R2 SP1 (x64)
Windows Server 2012 (x64)
Red Hat Enterprise Linux 6.1 (x86/x64)
Red Hat Enterprise Linux 6.4 (x86/x64)
SUSE Linux Enterprise Server 11.3 (x86/x64) |
| Board Management |
- |
| PSU Connectors |
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector |
| Retail Packaging Content |
1 x Driver CD
1 x I/O shield
1 x User manual
2 x SATA II 3Gb/s cables (500mm) |
| Reference Numbers |
Retail: 9M6LASLMR-00
Bulk: 9M6LASLNR-00 |
