| Form Factor |
Mini-ITX
170W x 170D (mm) |
| CPU |
Supports Intel® Xeon® processor E3-1200 V3 & V4 product families
Supports 4th gen Intel® Core™ i3, Pentium® and Celeron® processors*
*If used with non-ECC memory, supported on client OS only. If used with ECC memory, supported on both client and server OS. |
| Socket |
1 x LGA 1150 |
| Chipset |
Intel® C226 |
| Memory |
2 x DIMM slots
Supports unbuffered ECC or non-ECC UDIMM modules
Supports single rank and dual rank UDIMM modules
Up to 16GB
1333/1600/(1866*) MHz*Supported by Intel® Xeon® E3-1200 V4 processors only |
| LAN |
2 x GbE LAN ports (Intel® I210-AT) |
| Video |
Integrated in Aspeed® AST2300
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
(Aspeed® AST1300 in option) |
| Audio |
- |
| SAS |
- |
| SATA |
5 x SATA III 6Gb/s ports |
| RAID |
Intel® SATA RAID 0/1/10/5 |
| Expansion Slots |
1 x PCIe x16 (Gen3 x16 bus) slot |
| Internal I/O |
1 x Front panel VGA header
1 x 24-pin ATX main power connector
1 x 4-pin 12V auxiliary power connector
1 x PCIe x16 and x8 bandwidth switch jumper
1 x CPU fan header
1 x Front panel header
3 x System fan headers
1 x PMBus connector
1 x USB 3.0 header
1 x USB 2.0 header
1 x HDMI connector
1 x SATA port 4 DOM support jumper
1 x Case open intrusion header
1 x Battery power cable connector
5 x SATA III 6Gb/s ports
1 x SATA SGPIO header
1 x Clear CMOS jumper
1 x ME update jumper
1 x BIOS recovery jumper
1 x BMC readiness LED
1 x IPMB connector
1 x TPM header |
| Rear I/O |
2 x USB 2.0
1 x VGA
1 x Serial
2 x RJ45
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button |
| TPM |
1 x TPM header |
| OS Supported |
Windows Server 2012 R2 (x64)
Windows Server 2008 R2 (x64)
Red Hat Enterprise Linux 5.9 (x86/x64)
Red Hat Enterprise Linux 6.4 (x86/x64)
SUSE Linux Enterprise Server 11.3 (x86/x64)
VMware ESXi 5.0 / 5.1 / 5.1 U1 / 5.1 U2 |
| Board Management |
Aspeed® AST2300 management controller
Avocent® MergePoint IPMI 2.0 web interface:Network settings
Network security settings
Users control
Services settings
IPMI settings
Sessions control
LDAP settings
Power control
Voltages, fans and temperatures monitoring
System event log
Events management (platform events, trap settings, email settings)
Serial Over LAN
vKVM & vMedia (launch, configuration)
|
| PSU Connectors |
1 x 24-pin ATX main power connector
1 x 4-pin 12V auxiliary power connector |
| Retail Packaging Content |
1 x Driver CD
1 x I/O shield
1 x Manual
1 x SATA III 6Gb/s cable
2 x SATA II 3Gb/s |
| Reference Numbers |
Retail:9M6LISLMR-00
Bulk: 9M6LISLNR-00 |
