製品仕様
Dimension |
124W x 127.6D x 47.7H (mm) |
|---|---|
AI Accelerator |
NVIDIA® Jetson Orin™ NX Jetson Orin NX 16GB |
AI Performance |
Up to 100 TOPs |
CPU |
8-core Arm® Cortex®-A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 |
GPU |
NVIDIA Ampere architecture GPU with 1024 NVIDIA CUDA® cores and 32 Tensor cores |
Memory |
16GB 128-bit LPDDR5 DRAM (Module) |
Ethernet |
1 x GbE LAN Port |
Display output |
1 x HDMI 2.0 port, supporting a maximum resolution of 4096×2160 @60Hz |
Video input |
1 x HDMI input (Optional) 1 x VGA input (Optional) |
Storage |
1 x 2280 M.2 SSD (PCIe Gen3x2)(M2M2) |
Expansion-Slots |
1 x 2280 M.2 M-Key (PCIe Gen4x4, Support HDMI Capture card)(M2M1) 1 x 2230 M.2 E-Key |
Front I/O |
1 x USB 3.2 Gen 1 Type C, 5V/1A (not support USB to NVME dock) 2 x USB 2.0 1 x Power button with LED 1 x Recovery button |
Rear l/O |
1 x Scrw type DC Jack 1 x RJ45 LAN Port 1 x HDMI 2 x USB 3.2 Gen2x2 2 x External Antenna Holes (Optional) |
Power |
+19VDC |
Operation Temperature |
Operating temperature: 0°C to 40°C Operating humidity: 0-90% (non-condensing) Non-operating temperature: -20°C to 60°C Non-operating humidity: 0%-95% (non-condensing) |
Packing Content |
Carton size: 360 x 306 x 220 (mm) Packing Capacity: 5pcs Single Box size: 286 x 178 x 66 (mm) Single Box weight: Approx. 1.3kg Including: Power Cord : Optional (by region) PSU ADP 19V 65W 100-240VAC x 1 (P/N: 25EP2-10065Q-A3S) VESA Mount x 1 (P/N: 25HB1-TPL021-S8R) VESA Screws x1 (P/N: 25KSD-000002-C0R) |
Mounting |
VESA Mount 75/100 support |
Order Information |
9BQNORNXDMR-SI (Box packing) |
