TO15-S41-IA01
ORv3 GPUサーバー - 第5世代/第4世代 Intel® Xeon® Scalable - 1OU デュアルプロセッサ、PCIe Gen5対応GPU×8基、水冷式
1U 第5世代 Xeon ScalableXeon CPU Max第4世代 Xeon Scalable GPUサーバー
- 没入型環境対応サーバー
- 最大8基のシングルスロットGen5 GPUに対応
- 第5世代/第4世代 Intel® Xeon® スケーラブル・プロセッサーを2基搭載
- Intel® Xeon® CPU Maxシリーズを2基搭載
- 8チャネル DDR5 RDIMM、DIMMスロット16基
- デュアルROMアーキテクチャ
- Broadcom® BCM57416搭載の10Gb/s LANポート×2
- 15mm E1.S NVMeホットスワップベイ ×4
- SATAインターフェース搭載M.2スロット ×2（オプション）
- GPU用FHFL PCIe Gen5 x16スロット ×8
- LP PCIe Gen5 x8スロット ×2
- 48V DCバスバー電源ソリューション
製品仕様
| Dimensions (WxHxD, mm) | 1OU 537 x 45 x 805.7 |
|---|---|
| Open Rack Version | ORv3 |
| Motherboard | MS43-G21 |
| CPU | 5th Generation Intel® Xeon® Scalable Processors 4th Generation Intel® Xeon® Scalable Processors Intel® Xeon® CPU Max Series Dual processor, TDP up to 350W [注] CPUが1つしか搭載されていない場合、一部のPCIe機能やメモリ機能が利用できないことがあります。 |
| Memory | 16 x DIMM slots Support DDR5 RDIMM 8-Channel memory per processor 5th Gen Intel® Xeon®: Up to 5600 MT/s 4th Gen Intel® Xeon®: Up to 4800 MT/s Intel® Xeon® Max Series: Up to 4800 MT/s |
| LAN | Top: 2 x 10Gb/s LAN (1 x Broadcom® BCM57416) – Support NCSI function 1 x 10/100/1000 Mbps Management LAN |
| Storage | Top hot-swap: 4 x 15mm E1.S NVMe – (2 x NVMe from CPU_0, 2 x NVMe from CPU_1) Optional internal M.2 (COMTP61): 2 x M.2 (2280/22110), SATA, from CPU_1 |
| SAS | N/A |
| RAID | N/A |
| PCIe Expansion Slots | Riser Card CORC208 x 2: – 2 x FHFL x16 (Gen5 x16), from CPU_0, for GPUs – 2 x FHFL x16 (Gen5 x16), from CPU_1, for GPUs Riser Card CORC209 x 2: – 2 x FHFL x16 (Gen5 x16), from CPU_0, for GPUs – 2 x FHFL x16 (Gen5 x16), from CPU_1, for GPUs Riser Card CRSG01F x 2: – 1 x LP x16 (Gen5 x8), from CPU_0 – 1 x LP x16 (Gen5 x8), from CPU_1 |
| Top I/O | 2 x USB 3.2 Gen1 ports (Type-A) 1 x VGA port 2 x RJ45 ports 1 x MLAN port 1 x Power button with LED 1 x ID button with LED 1 x NMI button 1 x Reset button 1 x System status LED |
| System Management | ASPEED® AST2600 Baseboard Management Controller GIGABYTE Management Console web interface
|
| OS Compatibility | OS certifications: Windows Server 2022 |
| System Fans | N/A |
| Weight | Net Weight: 24.22 kg Gross Weight: 26.18 kg |
| Packaging Dimensions | 1100 x 715 x 249 mm |
| Packaging Content | 1 x TO15-S41-IA01 2 x CPU heatsinks 8 x GPU power cables (16-pin, 550mm) 6 x Carriers |
| Part Numbers | – Barebone package (5th/4th Gen): 6NTO15S41DR000IB01* – Barebone package (4th Gen): 6NTO15S41DR000IA01* – Motherboard: 9MS43G21UR-000* – CPU heatsink: 25ST1-25320R-C1R/25ST1-25320S-C1R – Riser card – CORC208: 9CORC208NR-00* – Riser card – CORC209: 9CORC209NR-00* – Riser card – CRSG01F: 9CRSG01FNR-00* – EDSFF Base board – COBP720: 9COBP720NR-00* – EDSFF Bypass card – CSPP010: 9CSPP010NR-00* – GPU power cable (16-pin, 550mm): 25CRI-5500B0-Y4R Optional parts: - M.2 expansion card – COMTP61: 9COMTP61NR-00* – RMA packaging: 6NTO15S41SR-RMA-I100 |
