製品仕様
| Dimension | 165W x 105D x 27H (mm) |
|---|---|
| CPU | Intel® Celeron® J6412 Processor 10nm, 4 cores, 4 threads, up to 2.60 GHz TDP 10W |
| Memory | 2 x DDR4 SO-DIMM sockets, Max. Capacity 32 GB Support Dual Channel DDR4 3200 MHz memory modules |
|
Ethernet |
2 x GbE LAN Ports |
|
Graphics Support |
Integrated Graphics Processor - Intel® UHD Graphics for 10th Gen Intel® Processors: 3 x HDMI 2.0 port, supporting a maximum resolution of 4096×2160 @60Hz (3 independent display outputs) |
| Audio | Realtek® audio codec |
| Expansion Slots | 1 x 2280 M.2 M-Key (PCIe x2, SATA 6Gb/s) 1 x 2230 M.2 E-Key 1 x 3042 M.2 B-key with SIM Slot (USB 3.2 Gen 1) |
| Front I/O | 2 x USB 3.2 Gen 1 1 x COM Port (RS-232)(RJ45 Type) 1 x Micro SD card slot 1 x Power button 1 x HDMI |
| Rear I/O | 1 x Headphone Jack 2 x RJ45 LAN Ports 2 x USB 3.2 Gen 1 2 x HDMI 1 x DC Jack |
| Side I/O | 3 x External Antenna Holes (Optional) |
|
Power |
+12~19VDC (Adapter 19V/65W) |
|
Operation Temperature |
Operating temperature: 0°C to 50°C Operating humidity: 0-90% (non-condensing) Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) |
|
Vibration During Operation |
Operation: IEC 60068-2-64, 3 Grms, random, 5 ~ 500 Hz, 1 hr / Per Axis, With SSD/M.2 2280 Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1 hr / Per Axis |
|
Shock During Operation |
Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With SSD |
| Packaging Content | Carton size: 416 x 359 x 257 (mm) Packing Capacity: 10pcs Single Box size: 209 x 169 x 75 (mm) Single Box weight: Approx. 1.5kg Including: Power Cord : Optional (by region) PSU ADP 19V 65W 100-240VAC x 1 (P/N: 25EP2-10065U-A3S) RJ45 to D-SUB Cable #24 150mm x 1 (P/N: 25CR0-150400-S9R) VESA Mount Bracket x 1 (P/N: 25HB1-TPL021-S8R) VESA Mount screws x 1 (P/N: 25KSD-000002-C0R) |
| Ordering Information | System: 6BQS6412AMR-SI (Box packing) |
