製品仕様
| Form Factor | CEB (12” x 10.5”) |
|---|---|
| CPU | Dual Intel Xeon processor 5500/ 5600 series |
| Chipset | Intel 5500 chipset with Intel ICH10R |
| Memory | 6 DDR3 DIMM sockets support registered or ECC unbuffered 6 channel native 1066/ 1333MHz |
| LAN | 2 Gigabit LAN (Intel 82567LM + Intel 82574L) |
| Video | XGI Volari Z9s 32MB DDR2 |
| SATA | 6 ports SATA 3Gbps via Intel ICH10R |
| RAID | Intel SW RAID 0/ 1/ 5/ 10 Optional 8 ports SAS 6Gbps HW RAID add-on card: GC-RLE087-RH Optional 8 ports SAS 6Gbps SW RAID add-on card: GC-RLE086-RH |
| Expansion Slots | 1 PCI Express 2.0 x16 2 PCI Express 2.0 x4 (x8 mechanical) 1 PCI Express 1.0 x4 (x8 mechanical) 1 PCI |
| Board Management | Hardware Monitor |
| Reference Numbers | 9M7TCSV10R-00 |
