製品仕様
| Form Factor | 267 x 305 mm |
|---|---|
| CPU | 2 x Intel Xeon 5500/ 5600 Series (LGA1366) |
| Chipset | Intel 5500 + ICH10R |
| Memory | 6 x 3 chanels DDR3 slots RDIMM or ECC UDIMM 1333/ 1066MHz |
| LAN | 2 x GbE controllers (Intel 82574L) |
| Video | ASPEED 1300 128MB DDR3 |
| SATA | 6 x SATA 3Gbp/s |
| RAID | Intel SW RAID 0/ 1/ 5/ 10 optional 8-ports SAS HW RAID card optional 8-ports SAS SW RAID card |
| Expansion Slots | 1 x PCIe 2.0 x16 2 x PCIe 2.0 x4 (x8 mechanical) 1 x PCIe x1 1 x PCI |
| Rear I/O | 1 x VGA 1 x COM 4 x USB 2.0 2 x RJ45 |
| Board Management | HW Monitor |
