製品仕様
| CPU | Build in Intel® Socket 2011-v3 Core™ i7 Processors Supports Intel® 22 nm CPU Supports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. Intel® Socket 2011-v3 for Intel® Xeon® processor E5-1600 v3 product family Intel® Socket 2011-v3 for Intel® Xeon® processor E5-2600 v3 product family |
|---|---|
| Chipset | Intel® X99 |
| Memory | 8 x DIMM, Max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory *1 8 x DIMM, Max. 128GB, DDR4 2133/1866* MHz ECC, Un-buffered Memory *2 8 x DIMM, Max. 128GB, DDR4 2133/1866* MHz ECC, Register Memory *2 Quad Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. ** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
| Multi-GPU Support | Supports NVIDIA® 3-Way SLI™ Technology *3 Supports AMD Quad-GPU CrossFireX™ Technology |
| Expansion Slots | 40-Lane CPU- 5 x PCIe 3.0/2.0 x16 (single at x16, dual at x16/x16, triple at x16/x16/x8, quintuple at x8/x8/x8/x8/x8 mode) 28-Lane CPU- 5 x PCIe 3.0/2.0 x16 (single at x16, dual at x16/x8, quad at x8/x8/x8/x4 mode) *4 |
| Storage | Intel® X99 chipset : 8 x SATA 6Gb/s port(s), *5 1 x SATA Express port, gray, , compatible with 2 x SATA 6.0 Gb/s ports 1 x M.2 Socket 3, gray, *6 Support Raid 0, 1, 5, 10 Supports Intel® Smart Connect Technology |
| LAN | Intel® I210-AT, 2 x Gigabit LAN Controller(s) 1 x Management LAN |
| Audio | Realtek® ALC1150 8-Channel High Definition Audio CODEC featuring Crystal Sound 2 - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, Front Panel MIC Jack-retasking - High quality 109 dB SNR stereo playback output (Line-out at rear) and 104 dB SNR stereo playback input (Line-in) - High-fidelity audio OP AMP(s) Audio Feature : - DTS Ultra PC II - DTS Connect - Optical S/PDIF out port(s) at back panel - BD Audio Layer Content Protection - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals - Audio amplifier: Provides the highest-quality sound for headphone and speakers Premium Japanese-made 12K hours capacitors - Absolute Pitch 192khz/24bit true BD lossless sound Separate layer for left and right track, ensuring both sound deliver equal quality |
| USB Ports | Intel® X99 chipset : 6 x USB 3.1 Gen 1 port(s) (2 at back panel, , 4 at mid-board) Intel® X99 chipset : 6 x USB 2.0/1.1 port(s) (2 at back panel, , 4 at mid-board) ASMedia® USB 3.0 controller : 2 x USB 3.1 Gen 1 port(s) (2 at back panel, +blue) |
| Workstation Feature | 5 x PCIe x 16 slot(s) ASUS Dr. Power 12K hours Capacitors ProCool Power Connector Q-Code Logger |
| Special Features | ASUS TPU : - TPU switch ASUS EPU : - EPU - EPU switch ASUS Digital Power Design : - Industry leading Digital 8 Phase Power Design - Industry leading Digital 4 Phase DRAM Power Design - CPU Power Utility - DRAM Power Utility ASUS Exclusive Features : - USB BIOS Flashback® - MemOK! - Ai Charger+ - USB Charger+ - M.2 & SATA Express - Disk Unlocker - Turbo LAN - Crystal Sound 2 - EZ XMP ASUS Exclusive Features ASUS EZ DIY : - ASUS O.C. Tuner - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - Push Notice ASUS Q-Design : - ASUS Q-Shield - ASUS Q-Code - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Slot - ASUS Q-DIMM Media Streamer |
| Operating System Support | Windows® 8.1 86x64 Windows® 8 86x64 Windows® 7 86x64 Windows® Server 2008 R2 Windows® Server 2012 R2 |
| Back I/O Ports | 2 x LAN (RJ45) port(s) 4 x USB 3.1 Gen 1 (blue) 2 x USB 2.0 (one port can be switched to USB BIOS Flashback®) *7 1 x Optical S/PDIF out 8 x Audio jack(s) 1 x USB BIOS Flashback® Button(s) 1 x Q-Code Logger button 1 x 8-channel Audio I/O 1 x Management LAN |
| Internal I/O Ports | 1 x AAFP connector 2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x SATA Express connector: gray, compatible with 2 x SATA 6.0 Gb/s ports 1 x M.2 Socket 3 for M Key, type 2260/2280 devices 1 x TPM connector(s) 1 x TPM header 8 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x CPU OPT Fan connector(s) (1 x 4 -pin) 4 x Chassis Fan connector(s) (4 x -pin) 1 x S/PDIF out header(s) 2 x 8-pin EATX 12 V Power connector 1 x 6-pin EATX 12 V_1 Power connector(s) 1 x 24-pin EATX Power connector(s) 1 x EZ XMP switch 1 x AUX panel header(s) 1 x SMBus header(s) 1 x System panel(s) 1 x DRCT header(s) 1 x MemOK! button(s) 1 x TPU switch(es) 1 x EPU switch(es) 1 x Power-on button(s) 1 x Reset button(s) 1 x Clear CMOS button(s) 1 x Dr.Power switch(es) 1 x 3-pin CHASSIS(Chassis intrusion) connector |
| Accessories | User |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard , F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information. |
| Manageability | WfM 2.0, DMI 2.7, WOL by PME, PXE |
| Support Disc | Drivers、ASUS Utilities、EZ Update 、Anti-virus software (OEM version) |
| Form Factor | ATX Form Factor *8 12 inch x 10 inch ( 30.5 cm x 25.4 cm ) |
| Environment | Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing) |
| Note | *1 When installing Intel® Socket 2011-v3 Core™ i7 Processors *2 When installing Intel® Xeon® E5-1600 v3/2600 v3 Processor *3 Supports up to 2-Way SLI™, When installing 28 lanes processor *4 When installing 28-Lane CPU,PCIe 3.0/2.0x16_4 cannot work *5 4 x right angle connectors from controller 1, x vertical connectors from controller 2 *6 with M Key, type 2260/2280 storage devices support (SATA/PCIE mode), M.2 Socket 3 shares bandwidth with SATAExpress *7 1 supports USB BIOS Flashback®, 1 supports Q-Code Logger *8 EEB Mounting Hole Location |
