製品仕様
| CPU | Intel® Socket 1150 for 4th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron®/Xeon® E3-1200/12x5 v3 series Processors Supports Intel® 22 nm CPU * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. |
|---|---|
| Chipset | Intel® Z87 |
| Memory | 4 x DIMM, Max. 32GB, DDR3 2800(O.C.)/2666(O.C.)/2600(O.C.)/2500(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/1866(O.C.)/1800/1600/1333 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
| Graphic | Integrated Graphics Processor *1 Multi-VGA output support : HDMI/DisplayPort /Mini DisplayPort ports *2 - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz - Supports DisplayPort with max. resolution 4096 x 2160 @ 24 Hz / 3840 x 2160 @ 60 Hz Maximum shared memory of 1024 MB Supports up to 3 displays simultaneously |
| Multi-GPU Support | Supports NVIDIA® 4-Way SLI™ Technology Supports AMD 4-Way CrossFireX Technology |
| Expansion Slots | 4 x PCIe 3.0/2.0 x16 (dual x16 or x16/x8/x8 or quad x8) 2 x PCIe 2.0 x1 |
| Storage | Intel® Z87 chipset : 6 x SATA 6Gb/s port(s), yellow Support Raid 0, 1, 5, 10 Marvell® PCIe 9230 controller : 4 x SATA 6Gb/s port(s), black Support Raid 0, 1, 10 ASMedia® ASM1061 controller : 2 x eSATA 6Gb/s port(s), red |
| LAN | Intel® I210, 2 x Gigabit LAN Controller(s) |
| Audio | Realtek® ALC1150 8-Channel High Definition Audio CODEC - Supports : Multi-streaming, Front Panel Jack-retasking - High quality 112 dB SNR stereo playback output (Line-out at rear) and 104 dB (Line-in) Audio Feature : - Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound - DTS Ultra PC II - DTS Connect - Optical S/PDIF out port(s) at back panel - BD Audio Layer Content Protection |
| IEEE 1394 | 1 x IEEE 1394a port(s) (1 at mid-board) |
| USB Ports | Intel® Z87 chipset : 3 x USB 3.1 Gen 1 port(s) (1 at back panel, blue, 2 at mid-board) Intel® Z87 chipset : 9 x USB 2.0/1.1 port(s) (4 at back panel, , 5 at mid-board) ASMedia® USB 3.0 controller : 3 x USB 3.1 Gen 1 port(s) (3 at back panel, blue) |
| Workstation Feature | 4 x PCIe x 16 slot(s) Quick Gate: 1 x vertical USB 2.0 on board ASUS Dr. Power |
| Special Features | ASUS Dual Intelligent Processors 4 with 4-Way Optimization : - The tuning key perfectly consolidates ASUS-exclusive DIGI+ Power Control, TPU, EPU, and Fan Xpert 2 optimize the digital power setting, system performance, power saving and whole system cooling configuration ASUS EPU : - EPU - EPU switch ASUS Digital Power Design : - Industry leading Digital 8 Phase CPU Power Design - Industry leading Digital 2 Phase DRAM Power Design - ASUS DIGI+ VRM Utility - CPU Power Utility - DRAM Power Utility ASUS Exclusive Features : - TurboV EVO - GPU Boost - USB BIOS Flashback® - MemOK! - AI Suite 3 - Ai Charger+ - USB Charger+ - Anti-Surge - Onboard Button : Power/Reset - Front Panel USB 3.0 Support - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface - ASUS SSD Caching II - Network iControl - USB 3.0 Boost - Disk Unlocker ASUS EZ DIY : - DirectKey - Precision Tweaker 2 - ASUS O.C. Profile - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - Multi-language BIOS ASUS Q-Design : - ASUS Q-Shield - ASUS Q-Code - ASUS Q-LED (CPU, DRAM, VGA) - ASUS Q-Slot - ASUS Q-DIMM - ASUS Q-Connector 100% All High-quality Conductive Polymer Capacitors Overclocking Protection : - ASUS C.P.R.(CPU Parameter Recall) |
| Back I/O Ports | 1 x PS/2 keyboard/mouse combo port(s) 1 x DisplayPort 1 x HDMI 2 x eSATA 6Gb/s 2 x LAN (RJ45) port(s) 4 x USB 3.1 Gen 1 4 x USB 2.0 (one port can be switched to USB BIOS Flashback®) 1 x Optical S/PDIF out 6 x Audio jack(s) 1 x USB BIOS Flashback® Button(s) 1 x Mini DisplayPort(s) |
| Internal I/O Ports | 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin, blue) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x USB 2.0/1.1 vertical port(s) 1 x TPM connector(s) 1 x COM port(s) connector(s) 10 x SATA 6Gb/s connector(s) 1 x mSATA connector 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x CPU OPT Fan connector(s) (1 x 4 -pin) 4 x Chassis Fan connector(s) (4 x 4 -pin) 1 x S/PDIF out header(s) 2 x 8-pin EATX 12 V Power connector 1 x 6-pin EATX 12 V_1 Power connector(s) 1 x 24-pin EATX Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 1 x Chassis Intrusion connector(s) 1 x DirectKey Button(s) 1 x MemOK! button(s) 1 x TPU switch(es) 1 x EPU switch(es) 1 x Dr.Power switch(es) |
| Accessories | User |
| BIOS | 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions, and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Manageability | WfM 2.0, DMI 2.7, WOL by PME, PXE |
| Support Disc | Drivers ASUS Utilities ASUS Update Anti-virus software (OEM version) |
| Operating System | Windows® 8 32/64-bit Windows® 7 32/64-bit |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| Note | *1 Intel® HD Graphics support *2 DisplayPort 1.2 Multi-Stream Transport compliant, supports DisplayPort 1.2 monitor daisy chain up to 3 displays *3 These SATA ports are for data hard drivers only. ATAPI devices are not supported. *4 supports ASUS USB 3.0 Boost |
