製品仕様
| CPU | Intel® Socket 1150 for 4th Generation Xeon® E3-1200/12x5 v3 series Processors Supports Intel® 22 nm CPU * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for CPU support list |
|---|---|
| Chipset | Intel® C226 |
| Memory | 4 x DIMM, Max. 32GB, DDR3 1600/1333 MHz ECC, Non-ECC, Un-buffered Memory Single Channel Memory Architecture ** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
| Graphic | Integrated Graphics Processor *1 Multi-VGA output support : HDMI/DVI/DisplayPort ports - Supports HDMI with max. resolution 4000 x 2000 @ 24 Hz - Supports DVI with max. resolution 1920 x 1200 @ 60 Hz - Supports DisplayPort with max. resolution 3200 x 2000 @ 60 Hz Maximum shared memory of 1024 MB Supports Intel® HD Graphics, InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™ |
| Multi-GPU Support | Supports AMD 4-Way CrossFireX Technology |
| Expansion Slots | 3 x PCIe 3.0/2.0 x16 (x16 or dual x8 or x8/x4/x4) 1 x PCIe 2.0 x16 (x4 mode) 1 x PCIe 2.0 x1 (x1 mode) 2 x PCI |
| Storage | Intel® C226 Chipset : 6 x SATA 6Gb/s port(s), gray Support Raid 0, 1, 5, 10 Intel® Rapid Storage Technology supports |
| LAN | Intel® I210 |
| Audio | Realtek® ALC892 8-Channel High Definition Audio CODEC - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking |
| IEEE 1394 | 1 x IEEE 1394a port(s) (1 at mid-board) |
| USB Ports | Built-in Controller : 4 x USB 3.1 Gen 1 port(s) (2 at back panel, , 2 at mid-board) Built-in Controller : 9 x USB 2.0/1.1 port(s) (4 at back panel, , 5 at mid-board) |
| Workstation Feature | 4 x PCIe x 16 slot(s) G.P. Diagnosis Card bundled Quick Gate: 1 x vertical USB 2.0 on board ASUS Dr. Power |
| Special Features | ASUS EPU : - EPU - EPU switch ASUS Power Design : - 4 +2 Phase Power Design ASUS Exclusive Features : - MemOK! - AI Suite 3 - Anti-Surge - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface - Network iControl - USB 3.0 Boost ASUS Quiet Thermal Solution : - Stylish Fanless Design Heat-sink solution - ASUS Fan Xpert 2 ASUS EZ DIY : - ASUS CrashFree BIOS 3 - ASUS EZ Flash ASUS Q-Design : - ASUS Q-Connector |
| Back I/O Ports | 1 x PS/2 keyboard/mouse combo port(s) 1 x DVI-I 1 x DisplayPort 1 x HDMI 2 x LAN (RJ45) port(s) 2 x USB 3.1 Gen 1 4 x USB 2.0 1 x Optical S/PDIF out 6 x Audio jack(s) 1 x USB BIOS Flashback® Button(s) |
| Internal I/O Ports | 1 x AAFP connector 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x USB 2.0/1.1 vertical port(s) 1 x TPM header 1 x LPT1 header 1 x COM port(s) connector(s) 6 x SATA 6Gb/s connector(s) 1 x IEEE 1394a connector(s) 1 x CPU fan with PWM control 4 x Chassis Fan connector(s) 1 x S/PDIF out header(s) 1 x 24-pin ATX Power connector 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel connector(s) (1 x 20 -pin) 1 x MemOK! button(s) |
| Accessories | User |
| BIOS | 64 Mb Flash ROM, EFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash Utility, ASUS CrashFree BIOS 3 |
| Manageability | WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE |
| Operating System | Windows® 8 32/64-bit Windows® 7 32/64-bit |
| Note | *1: Only using processors which feature Intel HD Graphics,Intel integrated graphics could enable. |
