製品仕様
| CPU | Intel® Core™ i7 Processors Intel® Socket 2011 for Xeon® E5-1600/E5-1600 v2 processors Intel® Socket 2011 for Xeon® E5-2600/E5-2600 v2 processors Supports Intel® Turbo Boost Technology 2.0 * Refer to www.asus.com for CPU support list |
|---|---|
| Chipset | Intel® X79 |
| Memory | 8 x DIMM, Max. 64GB, DDR3 2400(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz ECC, Non-ECC, Un-buffered Memory Quad Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. ** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
| Multi-GPU Support | Supports NVIDIA® 4-Way SLI™ Technology Supports AMD 4-Way CrossFireX Technology |
| Expansion Slots | 7 x PCIe 3.0/2.0 x16 (single x16 or dual x16/x16 or triple x16/x16/x16 or quad x16/x16/x16/x16 or seven x16/x8/x8/x8/x16/x8/x8, black+blue) * |
| Storage | Intel® X79 chipset : 2 x SATA 6Gb/s port(s), white 4 x SATA 3Gb/s port(s), blue Support Raid 0, 1, 5, 10 Marvell® PCIe 9230 controller : 4 x SATA 6Gb/s port(s), white Support Raid 0, 1, 10 ASMedia® PCIe SATA controller : 2 x eSATA 6Gb/s port(s), red Support port multiplier support |
| LAN | Intel® I210, 2 x Gigabit LAN Controller(s) |
| Audio | Realtek® ALC1150 8-Channel High Definition Audio CODEC - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking Audio Feature : - Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound - DTS Surround Sensation UltraPC - Optical S/PDIF out port(s) at back panel |
| IEEE 1394 | VIA® 6315N controller 1 x IEEE 1394a port(s) |
| USB Ports | ASMedia® USB 3.0 controller : 4 x USB 3.1 Gen 1 port(s) (2 at back panel, blue, 2 at mid-board) Intel® X79 chipset : 13 x USB 2.0 port(s) (10 at back panel, black, 3 at mid-board) |
| Workstation Feature | 7 x PCIe x 16 slot(s) Quick Gate: 1 x vertical USB 2.0 on board ASUS WS Diag. LED ASUS Dr. Power |
| Special Features | ASUS Xtreme Design : ASUS TPU : - TPU switch ASUS EPU : - EPU ASUS Digital Power Design : - Industry leading Digital 8 + 2 Phase CPU Power Design - Industry leading Digital 2 + 2 Phase DRAM Power Design - CPU Power Utility - DRAM Power Utility ASUS Exclusive Features : - MemOK! - AI Suite II - Ai Charger+ - Front Panel USB 3.0 Support - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface - ASUS SSD Caching II - USB 3.0 Boost ASUS Quiet Thermal Solution : - Stylish Fanless Design Heat-pipe solution - ASUS Fan Xpert+ ASUS EZ DIY : - USB BIOS Flashback® - ASUS O.C. Profile - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - ASUS MyLogo 2 - Multi-language BIOS ASUS Q-Design : - ASUS Q-Shield - ASUS Q-Code - ASUS Q-Slot - ASUS Q-DIMM - ASUS Q-Connector |
| Back I/O Ports | 1 x PS/2 keyboard/mouse combo port(s) 2 x eSATA 6Gb/s 2 x LAN (RJ45) port(s) 2 x USB 3.1 Gen 1 (blue) 10 x USB 2.0 (one port can be switched to USB BIOS Flashback®) 1 x Optical S/PDIF out 8 x Audio jack(s) 1 x USB BIOS Flashback® Button(s) |
| Internal I/O Ports | 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x Vertical USB 2.0 port(s) 1 x TPM connector(s) 1 x COM port(s) connector(s) 6 x SATA 6Gb/s connector(s) 4 x SATA 3Gb/s connector(s) 1 x CPU Fan connector(s) (4 -pin) 1 x CPU OPT Fan connector(s) (4 -pin) 4 x Chassis Fan connector(s) (4 -pin) 1 x S/PDIF out header(s) 1 x 8-pin EATX 12 V Power connector 1 x 6-pin EATX 12 V_1 Power connector(s) 1 x 24-pin EATX Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) (Q-Connector) 1 x Chassis Intrusion connector(s) 1 x MemOK! button(s) 1 x TPU switch(es) 1 x EPU switch(es) 1 x Power-on button(s) 1 x Reset button(s) 1 x Clear CMOS jumper(s) 1 x Dr.Power switch(es) |
| Accessories | User |
| BIOS | 64 Mb Flash ROM, UEFI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3 |
| Manageability | WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE |
| Operating System | Fedora 17 Windows® 8 32/64-bit Windows® 7 32/64-bit RedHat® Enterprise Linux WS 6.3 32/64-bit Open SUSE 12.2 Ubuntu Desktop 12.10 *(Subject to change without any notice) *1 |
| Form Factor | CEB Form Factor 12 inch x 10.5 inch ( 30.48 cm x 26.67 cm ) |
| Note | * This motherboard is ready to support PCIe 3.0 SPEC. Functions will be available when using PCIe 3.0-compliant devices. Please refer to www.asus.com for updated details. *1 Linux OS only conduct installation test OK. |
