製品仕様
| CPU | Intel® Socket 1156 Core™ i7 Processor/Core™ i5 Processor Xeon 3400 series server processor Supports Intel® Turbo Boost Technology |
|---|---|
| Chipset | Intel® P55 Express Chipset Nvidia NF200*1 |
| Memory | 4 x DIMM, Max. 16 GB, DDR3 2133(O.C.)*/1600/1333/1066 Non-ECC,Un-buffered Memory Dual Channel memory architecture Support Intel Extreme Memory Profile (XMP) *Hyper DIMM support is subject to the physical characteristics of individual CPUs. Some hyper DIMMs only support one DIMM per channel. Please refer to Memory QVL for details. **Refer to www.asus.com or this user manual for the Memory QVL(Qualified Vendors Lists). |
| Expansion Slots | 2 x PCIe 2.0 x16 (@ x16 or x8) 2 x PCIe 2.0 x16 (@ x8) 1 x PCIe x16 (@ x4 ) 1 x PCIe x1 (@ x1) 1 x PCI |
| Multi-GPU Support | Supports NVIDIA® Geforce 3 way/2 way SLI™ techonology
Supports ATI® CrossFireX™ technology, up to Quad CrossFireX™ |
| Storage | Intel® P55 Express Chipset built-in 6 xSATA 3.0 Gb/s ports Intel® Matrix Storage Support RAID 0,1,5,10 |
| LAN | 2 x Realtek 81112L Dual Gb LAN - Support teaming function |
| Audio | ALC1200-GR 8-Channel High Definition Audio CODEC Multi-Streaming Jack-Sensing Front Panel Jack-Retasking Coaxial / Optical S/PDIF out ports at back I/O ASUS Noise-Filer |
| IEEE 1394 | VIA VT6308S controller supports 2 x 1394a ports |
| USB | 14 USB 2.0/1.1 ports |
| ASUS Unique Features | ASUS Hybrid Processor - TurboV EVO
- Auto Tuning, TurboV ASUS 24 Hybrid Phase Design* - T.Probe Technology for Active Cooling - 16+3 Phase Power Design *24 Hybrid Phase = 16+3 Phase x T.Probe ASUS Hybrid OS - Express Gate ASUS Exclusive Features - MemOK! - ASUS EPU ASUS Quiet Thermal Solution - ASUS Fanless Design: Heat-pipe solution - ASUS Fanless Design: Stack Cool 2 - ASUS Fan Xpert ASUS Crystal Sound - ASUS Noise Filter ASUS EZ DIY - ASUS Q-Shield - ASUS Q-Connector - ASUS O.C. Profile - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - ASUS MyLogo 2 - Multi-language BIOS ASUS Q-Design - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-DIMM |
| ASUS Workstation Special Features | 5 PCIe x 16 slots
G.P. Diagnosis Card bundled ASUS SASsaby-M/SASsaby Cards support ASUS WS Diag. LED ASUS WS Heartbeat |
| Overclocking Features | Precision Tweaker 2 - vCore: Adjustable CPU voltage at 0.00625V increment - vIMC: Adjustable IMC voltage at 0.00625V increment - vDRAM Bus: 81-step DRAM voltage control - vPCH: 2-step chipset voltage control - vCPU_PLL: 4-step reference voltage control SFS (Stepless Frequency Selection) - PCI Express frequency tuning from 100MHz up to 200MHz at 1MHz increment - Internal Base Clock tuning from 80MHz up to 500MHz at 1MHz increment Overclocking Protection - ASUS C.P.R.(CPU Parameter Recall) |
| Back Panel I/O Ports | 1 x PS/2 Keyboard/Mouse Combo port 1 x S/PDIF Out (Coaxial + Optical) 1 x IEEE 1394a 2 x LAN(RJ45) port 8 x USB 2.0/1.1 8 -Channel Audio I/O |
| Internal I/O Connectors | 24-pin EATX Power connector
8-pin EATX +12V Power connector CPU fan with PWM control Chassis fan1 with Q-fan control Chassis fan2 with Q-fan control Chassis fan3 with Q-fan control PWR fan CD audio in 1 x COM port connector 1 x USB connectors support additional 2 USB ports 2 x USB 2.0/1.1 ports 20-pin Panel connector 1 x IEEE 1394a port TPM header S/PDIF Out header Front panel connector 1x MemOK! buttom |
| BIOS | 16 Mb Flash ROM , AMI BIOS, Green, PnP, DMI v2.0, Wfm2.0, ACPI v2.0a, SMBIOS v 2.6 |
| Manageability | WfM 2.0,DMI 2.0,WOL by PME,WOL/WOR by PME,WOR by PME,PXE |
| Accessories | 1 x 2-port USB and 1-port 1394a module
ASUS Q-Shield 1 x ASUS SLI bridge connector 1 x ASUS 3 way SLI bridge board User |
| Support Disc | Drivers
Anti-virus software (OEM version) ASUS Update ASUS Utilities |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.5 cm ) |
