製品仕様
| Processor / System Bus | 2 x Socket G34 compatible AMD Opteron™ 6100 series AMD Opteron™ 6200 series AMD Opteron™ 6300 series HyperTransport™ Technology 3.0 6.4 GT/s per link (triple link) *Please refer to overview for details |
|---|---|
| Core Logic | AMD SR5690 AMD SP5100 |
| Memory | Total Slots : 16 (4-channel per CPU, 8 DIMM per CPU) Capacity : Maximum up to 256GB RDIMM Memory Type : DDR3 1600/1333/1066/800 UDIMM* DDR3 1600/1333/1066/800 RDIMM* Memory Size : 16GB, 8GB, 4GB, 3GB, 2GB, 1GB RDIMM 8GB, 4GB, 2GB, 1GB UDIMM |
| Expansion Slots | Total Slot : 6 Slot Location 1 : PCI 32bit/33MHz Slot Location 2 : PCI-E x16 (Gen2 X8 Link) Slot Location 3 : PCI-E x16 (Gen2 X16 Link), Auto switch to x8 link if slot 2 is occupied Slot Location 4 : PCI-E x8 (Gen2 X4 Link) Slot Location 5 : PCI-E x16 (Gen2 X16 Link) Slot Location 6 : PCI-E x16 (Gen2 X16 Link), Auto turn off if slot 5 is occupied, For 1U FH/FL Card, MIO supported Additional Slot 1 : PIKE Slot for Stroage expansion Follow SSI Location# |
| Form Factor | EEB (12"x13") |
| ASUS Features | Fan Speed Control Rack Ready (Rack and Pedestal dual use) |
| Storage | SATA Controller : AMD SP5100 6 x SATA2 300MB/s PROMISE® SW RAID (For Linux/Windows) (Support Software RAID 0, 1, 5, 10 ) SAS/SATA Controller : ASUS PIKE 2008 8-port SAS2 6G RAID card (Optional) ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card(Optional) ASUS PIKE 2108-32PD 8-port SAS2 6G RAID card (Optional) ASUS PIKE 2208 8-port SAS 6G HW RAID card (Optional) ASUS PIKE 2308 8-port SAS 6G RAID card (Optional) ASUS PIKE 9230 4-port SATA 6G RAID card (Optional) |
| Networking | 2 x Intel® 82574L + 1 x Mgmt LAN |
| Graphic | Aspeed AST2050 with 8MB VRAM |
| On Board I/O | 1 x PSU Power Connector (24-pin SSI power connector + 8-pin SSI 12V + 8-pin SSI 12V power connector) 1 x Management Connector , Onboard socket for management card 3 x USB pin header , Up to 6 Devices 1 x Internal A Type USB Port 8 x Fan Header , 4pin (3pin/4pin fan dual support) 2 x SMBus 1 x Serial Port Header 1 x TPM header 1 x PS/2 KB/MS port |
| Back I/O Ports | 1 x External Serial Port 2 x External USB Port 1 x VGA Port 2 x RJ-45 1 x PS/2 KB/Mouse |
| Management Solution | Out of Band Remote Management: Optional ASMB4-iKVM for KVM-over-Internet |
| Regulatory Compliance | CE, C-Tick, FCC(Class B) |
| Environment | Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing) |
| Accessories | Gift Box Pack : 1 x User |
| Monitoring | CPU Temperature Fan RPM |
| Note | * DDR3 1600 can only be supported with AMD Opteron™ 6300/6200 series processor |
