製品仕様
| Processor / System Bus | 2 x Socket 2011 Intel® Xeon® processor E5-2600 product family (135W) * Intel® Xeon® processor E5-2600 v2 product family (135W) QPI 6.4 / 7.2 / 8.0 GT/s *Refer to www.asus.com for CPU Support list |
|---|---|
| Core Logic | Intel® C602-A PCH |
| Memory | Total Slots : 8 (4-channel per CPU, 4 DIMM per CPU) Capacity : Maximum up to 256GB LRDIMM Memory Type : DDR3 1866*/1600/1333/1066 RDIMM DDR3 1866*/1600/1333/1066 UDIMM DDR3 1866*/1333/1066 LRDIMM Memory Size : 32GB, 16GB, 8GB, 4GB, 2GB RDIMM 8GB, 4GB, 2GB UDIMM 32GB, 16GB, 8GB LRDIMM |
| Expansion Slots | Total Slot : 5 Slot Location 2 : PCI-E x8 (Gen2 X4 Link) Slot Location 3 : PCI-E x16 (Gen3 X16 Link), Auto switch to x8 link if slot 4 is occupied Slot Location 4 : PCI-E x8 (Gen3 X8 Link) Slot Location 5 : PCI-E x16 (Gen3 X16 Link), Auto switch to x8 link if slot 6 is occupied Slot Location 6 : PCI-E x8 (Gen3 X8 Link), MIO supported Additional Slot 1 : PIKE Slot for Stroage expansion *1 Follow SSI Location# |
| Form Factor | ATX (12"x10") |
| ASUS Features | FAN speed control Rack Ready (Rack and Pedestal dual use) ASWM Enterprise |
| Storage | SATA Controller : Intel® C602-A AHCI 4 x SATA2 3Gb/s ports 2 x SATA3 6Gb/s ports Intel® Rapid Storage Technology Enterprise(RSTe) (For Windows Only) (Support Software RAID 0, 1, 5, 10 ) LSI® MegaRAID (For Linux/Windows) (Support Software RAID 0, 1, 10 ) SAS Controller : ASUS PIKE 2008 8-port SAS2 6G RAID card ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card ASUS PIKE 2108 8-port SAS2 6G RAID card ASUS PIKE 2208 8-port SAS 6G HW RAID card ASUS PIKE 2308 8-port SAS 6G RAID card |
| Networking | 2 x Intel® 82574L + 1 x Mgmt LAN |
| Graphic | Aspeed AST2300 with 16MB VRAM |
| On Board I/O | 1 x TPM header 1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector)*2 1 x PSU Power Connector (24-pin SSI power connector + 8-pin SSI 12V + 8-pin SSI 12V power connector)*3 1 x USB connector*4 2 x USB pin header , Up to 4 Devices 8 x Fan Header , 4pin 1 x SMBus 1 x Chassis Intruder 2 x Front LAN LED 1 x Serial Port Header 1 x Management Connector , Onboard socket for management card |
| Back I/O Ports | 1 x External Serial Port 4 x External USB Port ﹝2 x USB 3.1 Gen 1, 2 x USB 2.0﹞ 1 x VGA Port 2 x RJ-45 + 1 x Mgmt LAN 1 x PS/2 KB/Mouse |
| Management Solution | ASWM Enterprise Optional ASMB6-iKVM for KVM-over-Internet |
| EMI | US (FCC, CFR47 Part 15, Class B) Europe (CE, EN55022 & EN55024) |
| Environment | Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing) |
| Accessories | Gift Box Pack (1pcs per Carton): 6 x SATA Data Cables 1 x I/O Shield 1 x ASUS Mainboard Support CD 1 x ASWM Support CD 1 x User |
| Product SKUs | Standard Gift Box Pack Standard Bulk Pack |
| Monitoring | CPU Temperature Fan RPM |
| Note | * DDR3 1866 can only be supported with Intel® Xeon® processor E5-2600 v2 product family, refer to www.asus.com for latest momory AVL update * Refer to ASUS Server AVL for latest update *1 1* PIKE Slot for Storage expansion (Gen3 supported) *2 95W or below CPU only, Minimum requirement of ATX Power supply: 1) 500W 2) All +12V output ≧20A *3 Support Both ATX & SSI Power Supply *4 Type A USB socket |
