Supermicroのサーバ：5037MC-H8TRF
1. Intel® Xeon® processor E3-1200
family, Intel® 2nd Generation Core i3
& Intel® Pentium® family processors;
socket H2 (LGA 1155)***
2. 2x 3.5" Hot-swap SATA3 (6 Gbps)
3. 1x (x8) PCI-E 2.0 low-profile slot
4. Up to 32GB DDR3 ECC UDIMM
1333/1066MHz Memory support;
2 channels
5. 2x Intel 82580DB GbE LAN ports
6. 1x Dedicated LAN for IPMI Remote
Management
7. 4x 8cm Heavy duty fans with optimal
cooling zone
8. 1620W Redundant 80Plus Platinum
Level power supplies
Xeon E3-1200シリーズ対応の3U 8ノードベアボーン。
集約性が高く、わずか3Uのスペースの中に8ノードも搭載するこ とができ、ラックスペー スの集約に効果があります。また、電源を8ノードで共有することにより消費電力の削減にも効果があり、同等仕様のXeon 3400シリーズサーバ8台と比較した場合、約35%の削減することが可能です。メンテナンスのし易さも考慮した設計で、ノード、電源、HDD、FANは ホットスワップでの取り扱いが可能です。
高い集約性と消費電力削減効果が、複数のノードで構築するクラウドシステム基盤、専用・仮想等のホスティングサーバ、高速なレスポンス性能を要求されるフロントエンドサーバ等の用途に最適に機能します。
| 製品仕様 | |
|---|---|
| Product SKUs | |
| SuperServer | SYS-5037MC-H8TRF (Black) |
| マザーボード | |
| Motherboard | MBD-X9SCD-F ** |
| プロセッサ/キャッシュ | |
| CPU | Intel® Xeon® processor E3-1200 family, Intel® 2nd Generation Core i3 & Intel® Pentium® family processors*** Socket H2 (LGA 1155) |
| メモリ (per node) | |
| Memory Capacity | 4x 240-pin DDR3 DIMM sockets Supports up to 32 GB DDR3 ECC Un-Buffered memory (UDIMM) |
| Memory Type | 1333/1066MHz ECC DDR3, 240-pin gold-plated DIMMs |
| DIMM Sizes | 8GB, 4GB, 2GB, 1GB |
| Memory Voltage | 1.5 V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| オンボードデバイス (per node) | |
| Chipset | Intel® C204 PCH chipset* |
| SATA | 1x SATA DOM |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM over LAN support Winbond® WPCM450 BMC |
| Headers | 1 USB header & 1 Type A USB, TPM ready |
| Graphics | Matrox G200eW 16MB DDR2 |
| Super I/O | Nuvoton WPCM450RA0BX |
| Network Devices (per node) | |
| Micro-LP NIC | Intel® 82580DB, 2x Gigabit LAN ports iSCSI boot and PXE support Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output Intel® I/OAT 3 support for fast, scaleable, and reliable networking VMDq support for better performance of virtualization |
| 拡張スロット (per node) | |
| PCI-Express | 1 (x8) PCI-E 2.0 low-profile slot |
| 標準インターフェース (per node) | |
| Serial ATA | 2x SATA 3.0 ports (6Gbps) |
| LAN | 2x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port |
| KVM | 1x VGA, 1x COM, and 2x USB 2.0 ports |
| BIOS | |
| BIOS Type | 64Mb SPI Flash EEPROM with AMI BIOS |
| BIOS Features | Plug and Play (PnP) APM 1.2 ACPI 1.0 / 2.0 USB Keyboard support SMBIOS 2.3 RTC (Real Time Clock) Wakeup |
| Rear Window (each node) | |
| Switch | Power / UID |
| シャーシ | |
| Form Factor | 3U |
| Model | CSE-938H-R1620B |
| 外形寸法/重量 | |
| Height | 5.21" (132.5 mm) |
| Width | 17.26" (438.4 mm) |
| Depth | 23.2" (589 mm) |
| Weight | 62.2 lbs (28.21 kg) - barebone |
| Color | Black |
| フロントパネル | |
| Buttons | Power On/Off button |
| LEDs | Power LED Hard drive activity LED Network activity LED System Overheat LED UIO LED |
| ドライブベイ | |
| Hot-swap | 2x 3.5" hot-swap SATA3 (6Gbps) HDDs per node; up to 16 HDDs total Enterprise SATA HDD only recommended |
| 冷却機構 | |
| Fans | 4x 8cm Heavy duty fans with optimal cooling zone |
| 電源 | |
| Power Supply | 1620W high-efficiency redundant power supply |
| AC Input | 1000W: 100-120 V, 50-60 Hz, 12-10 Amp 1200W: 120-140 V, 50-60 Hz, 12-10 Amp 1620W: 180-240 V, 50-60 Hz, 10.5-8 Amp |
| DC Output+5V standby | 4 Amp |
| DC Output+12V | 1000W: 84 Amp 1200W: 100 Amp 1620W: 135 Amp |
| Certification | 80PLUS Platinum Certified[ Test Report ] |
| システム監視機能 | |
| CPU | Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory, Chipset Voltages. 6-Phase-switching voltage regulator with auto-sense from 0.8375V-1.60V |
| FAN | Cooling zone |
| Temperature | Monitoring for CPU and chassis environment |
| 動作環境/コンプライアンス | |
| Environmental Spec. | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| パーツリスト(付属品) | |||
|---|---|---|---|
| 型番 | 数量 | 内容 | |
| パーツリスト | |||
| Motherboard / Chassis | MBD-X9SCD-F | 8 | Super X9SCD-F Motherboard |
| Motherboard / Chassis | CSE-938H-R1620B | 1 | 3U Chassis |
| Cable 1 | CBL-0218L | 1 | 11.5CM KVM/SUVI 36PIN TO 9PIN/15PIN/2USB |
| Heatsink / Retention | SNK-P0047PS | 8 | 1U Passive CPU Heat Sink for X9 Generation Motherboards w/ Narrow ILM |
| Backplane | BPN-SAS-938H | 1 | Backplane for SC938, 16x 3.5" SAS/SATA |
| Micro-LP NIC | AOC-CG-i2-O-P | 8 | AOC-CG-I2-O-P |
| Riser Card | RSC-RR1U-E8-O-P | 8 | RSC-RR1U-E8 (Rev 3.10) |
| Power Supply | PWS-1K62P-1R | 2 | 1620W REDUNDANT POWER MODULE |
