Supermicroのサーバ：5037C-i
1. Single socket H2 (LGA 1155) supports
Intel® Xeon® E3-1200 & v2 series,
2nd Gen Core i3 processors*
2. Up to 32GB DDR3 ECC 1333MHz /
1600MHz* UDIMMs in 4 sockets
3. 2 PCI-E 3.0* x8 and 1 PCI-E 2.0 x4
in x8 Expansion Slots
4. Intel® 82579LM and 82574L,
2x Gigabit Ethernet LAN ports
5. 9x USB 2.0 ports
(2 rear + 6 via header + 1 Type-A)
6. 2x 5.25" external drive bays,
4x 3.5" internal drive bays,
1x 3.5" external drive bay (OEM),
90° rotating hard drive cage
7. 300W High-efficiency Power Supply
| 製品仕様 | |
|---|---|
| Product SKUs | |
| SuperServer | SYS-5037C-i (Black) |
| マザーボード | |
| Motherboard | MBD-X9SCL |
| プロセッサ/キャッシュ | |
| CPU | Intel® Xeon® processor E3-1200 & v2 series, Intel® 2nd Gen Core i3 processors * Socket H2 (LGA 1155) |
| メモリ | |
| Memory Capacity | 4x 240-pin DDR3 DIMM sockets Supports up to 32 GB DDR3 ECC Un-Buffered memory (UDIMM) |
| Memory Type | 1600*/1333/1066MHz ECC DDR3, 240-pin gold-plated DIMMs |
| DIMM Sizes | 8GB, 4GB, 2GB, 1GB |
| Memory Voltage | 1.5 V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| オンボードデバイス | |
| Chipset | Intel® C202 PCH chipset |
| SATA | 6x SATA 2.0 (3Gbps) w/ RAID 0, 1, 5, 10 |
| Network Controllers | Intel® 82579LM and 82574L, 2x Gigabit LAN ports Virtual Machine Device Queues High efficient I/O overhead Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output Intel® I/OAT 3 support for fast, scaleable, and reliable networking VMDq support for better performance of virtualization |
| Graphics | Matrox G200eW 16MB DDR2 |
| Super I/O | Nuvoton NCT6776F |
| BMC | Nuvoton WPCM450RA0BX |
| 拡張スロット | |
| PCI-Express | 2 PCI-E 3.0* x8 slots 1 PCI-E 2.0 x4 in x8 slot |
| 標準インターフェース | |
| Serial ATA | 6 SATA 2.0 ports 6 SATA hard drives supported |
| LAN | 2x RJ45 LAN ports |
| USB | 2x USB rear ports 1x USB Type-A 6x USB ports via header Total 9 USB 2.0 Compliant |
| VGA | 1x VGA port |
| Serial Port / Header | 2x Fast UART 16550 serial port(one header and one rear port) |
| BIOS | |
| BIOS Type | 32Mb SPI Flash EEPROM with AMI BIOS |
| BIOS Features | DMI 2.3 PCI 2.3 ACPI 1.0 / 2.0 USB Keyboard support SMBIOS 2.3 |
| シャーシ | |
| Form Factor | Mid-Tower |
| Model | CSE-731i-300B |
| 外形寸法/重量 | |
| Height | 14.25" (362 mm) |
| Width | 7.25" (184 mm) |
| Depth | 16.75" (425 mm) |
| Gross Weight | 24 lbs (10.89 kg) |
| Available Colors | Black |
| フロントパネル | |
| Buttons | Power On/Off button System Reset button |
| LEDs | Power LED Hard drive activity LED Network activity LED System Overheat LED |
| Ports | 2x Front side USB ports (USB 2.0 ready) |
| ドライブベイ | |
| Internal | 4x 3.5" tool-less HDD trays Enterprise SATA HDD only recommended |
| External | 2x 5.25" external drive bays 1x 3.5" external drive bay (OEM option) |
| 冷却機構 | |
| Fans | 1x 9cm (rear) PWM fan w/ tool-less design 1x 8cm (front) cooling fan (optional) Optimized Cooling Technology at 25dB Whisper-Quiet Operation |
| 電源 | |
| Power Supply | 300W AC power supply w/ PFC |
| AC Voltage | 100 - 240V, 50-60Hz, 5 Amp |
| DC Output | 5V + 12V + 3.3V - 12V < 290W |
| +5V | 19 Amp |
| +5V standby | 2.0 Amp |
| +12V | 11 Amp + 11.5 Amp |
| -12V | 0.15 Amp |
| +3.3V | 16.0 Amp |
| Certification | 80 PLUS Bronze Certified[ Test Report ] |
| システム監視機能 | |
| CPU | Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory, Chipset Voltages. 6-Phase-switching voltage regulator with auto-sense from 0.8375V-1.60V |
| FAN | Total of 5 fan headers supporting up to 5 fans |
| Temperature | Monitoring for CPU and chassis environment Thermal Control for 5x fan connectors PECI |
| 動作環境/コンプライアンス | |
| Environmental Spec. | Operating Temperature: 10°to 35°C (50°to 95°F) Non-operating Temperature: -40°to 70°C (-40°to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5 to 95% (non-condensing) |
| パーツリスト(付属品) | |||
|---|---|---|---|
| 型番 | 数量 | 内容 | |
| パーツリスト | |||
| Motherboard / Chassis | MBD-X9SCL | 1 | Super X9SCL Motherboard |
| Motherboard / Chassis | CSE-731i-300B | 1 | Mid-Tower Chassis |
| Cable 1 | CBL-0044L | 4 | SATA CABLE 61CM FLAT S-S PBF |
| CD | CDR-X9-UP | 1 | Driver CD for X9-UP series motherboard |
| Part | MCP-260-00027-0N | 1 | Std I/O shield for X8, H8, X7SB3 server MB (3rd LAN + 4xLAN) |
| オプションパーツリスト | |||
| CD-ROM & Accessory | DVM-LITE-DVD-HBT | Black 5.25" SATA DVD, LITEON, PBF | |
| CD-ROM & Accessory | DVM-LITE-DVDRW-HBT | Black 5.25" SATA DVD-RW, LITEON, PBF | |
| Heat Sink | SNK-P0046A4 | 2U ACTIVE CPU HS FOR INTEL LGA1156 | |
