Supermicroのサーバ：5017C-TF
1. Single socket H2 (LGA 1155) supports
Intel® Xeon® E3-1200 & v2 series,
2nd Gen Core i3 processors*
2. Intel® C204 PCH Chipset
3. 2x 3.5" Hot-swap SATA2/3 HDDs
4. 1x PCI-E 3.0* x8 FHFL slot
5. Up to 32GB DDR3 ECC 1333MHz /
1600MHz* UDIMMs in 4 sockets
6. Intel® 82579LM and 82574L,
2x Gigabit Ethernet LAN ports
7. IPMI 2.0 on Dedicated LAN port
8. 4x SATA 2.0 with RAID 0, 1, 5, 10
2x SATA 3.0 with RAID 0, 1, 5, 10
9. 350W Gold Level Power Supply
10. 1x Slim DVD-ROM Drive
11. Disk-on-module (DOM) power
connector
| 製品仕様 | |
|---|---|
| Product SKUs | |
| SYS-5017C-TF | SuperServer 5017C-TF (Black) |
| マザーボード | |
| Motherboard | Super X9SCM-F |
| プロセッサ/キャッシュ | |
| CPU | Intel® Xeon® processor E3-1200 & v2 series, Intel® 2nd Gen Core i3 processors * Socket H2 (LGA 1155) |
| メモリ | |
| Memory Capacity | 4x 240-pin DDR3 DIMM sockets Supports up to 32 GB DDR3 ECC Un-Buffered memory (UDIMM) |
| Memory Type | 1600*/1333/1066/800MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs |
| DIMM Sizes | 8GB, 4GB, 2GB, 1GB |
| Memory Voltage | 1.5 V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| オンボードデバイス | |
| Chipset | Intel® C204 PCH chipset |
| SATA | 4x SATA 2.0 (3Gbps) w/ RAID 0, 1, 5, 10 2x SATA 3.0 (6Gbps) w/ RAID 0, 1, 5, 10 |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Nuvoton WPCM450 BMC |
| Network Controllers | Intel® 82579LM and Intel® 82574L, 2x Gigabit Ethernet LAN ports Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output 1x Realtek RTL8201N PHY (dedicated IPMI) |
| VGA | Nuvoton WPCM450RA0BX |
| Super I/O | Nuvoton NCT6776F |
| Clock Generator | CK505 |
| 標準インターフェース | |
| Serial ATA | 6 SATA ports 6 SATA hard drives supported |
| LAN | 2x RJ45 LAN ports 1x RJ45 Dedicated IPMI LAN port |
| USB | 2x USB rear ports 1x USB Type-A 6x USB ports via header Total 9 USB 2.0 Compliant |
| Keyboard / Mouse | PS/2 keyboard and mouse ports |
| Serial Port / Header | 1x Fast UART 16550 serial port 1x internal header |
| シャーシ | |
| Form Factor | 1U Rackmount |
| Model | CSE-811TQ-350B |
| 外形寸法/重量 | |
| Height | 1.7" (43mm) |
| Width | 16.8" (426mm) |
| Depth | 22.6" (574mm) |
| Gross Weight | 38 lbs (16.5kg) |
| Available Colors | Black |
| フロントパネル | |
| Buttons | Power On/Off button System Reset button |
| LEDs | Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED |
| Ports | 2x USB ports |
| 拡張スロット | |
| PCI-E | 1x PCI-E 2.0 x8 slot |
| ドライブベイ | |
| Hot-swap | 2x 3.5" Hot-swap SATA2/3 HDDs w/ RAID |
| Peripheral Drives | |
| DVD-ROM | Slim DVD-ROM Drive |
| バックプレーン | |
| Backplane | SAS/SATA HDD Backplane(SAS support requires optional SAS controller) |
| 冷却機構 | |
| Fans | 2x 10cm 5K RPM PWM blower fans |
| 電源 | |
| Power Supply | 350W AC power supply w/ PFC |
| AC Voltage | 100-240 V, 50-60 Hz, 4.2-1.8 Amp |
| +5V | 18 Amp |
| +5V standby | 3 Amp |
| +12V | 29 Amp |
| +3.3V | 15 Amp |
| Certification | 80 PLUS Gold Certified[ Test Report ] |
| BIOS | |
| BIOS Type | 8Mb SPI Flash EEPROM with AMI BIOS |
| BIOS Features | DMI 2.3 PCI 2.3 ACPI 1.0 / 2.0 USB Keyboard support SMBIOS 2.3 |
| 動作環境/コンプライアンス | |
| RoHS | RoHS Compliant |
| Environmental Spec. | Operating Temperature: 10° to 35°C (50° to 95°F) Non-operating Temperature: -40° to 70°C (-40° to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5 to 95% (non-condensing) |
| 拡張スロット | |
| PCI-Express | 1x PCI-E 3.0 x8 Full-height Full-length slot* |
| パーツリスト(付属品) | |||
|---|---|---|---|
| 型番 | 数量 | 内容 | |
| パーツリスト | |||
| Motherboard / Chassis | MBD-X9SCM-F | 1 | Super X9SCM-F Motherboard |
| Motherboard / Chassis | CSE-811TQ-350B | 1 | 1U Chassis |
| Backplane | CSE-SAS-810TQ | 1 | CSE-SAS-810TQ-O-P |
| Cable 1 | CBL-0061L | 2 | 35CM, SATA CABLE, PB FREE |
| Cable 2 | CBL-0157L | 1 | 8pin to 8pin ribbon cable with tube for SGPIO, 40cm, PBF |
| Cable 3 | CBL-0341L | 1 | 1CH internal 10P to 4P USB 2.0 cable for LCD,DVD, 70cm |
| Adapter 1 | CDM-USATA-G-O-P | 1 | mini-SATA to USB adapter for slim DVD |
| Peripheral Drive *** | DVM-PNSC-DVD-SBT1 | 1 | BLACK PANASONIC SLIM DVD ROM SATA DRIVE |
| Peripheral Drive *** | DVM-TEAC-DVD-SBT1 | 1 | BLACK TEAC SLIM DVD ROM SATA DRIVE ROHS |
| CD | CDR-X9-UP | 1 | Driver CD for X9-UP series motherboard |
| Riser Card | CSE-RR1U-E8 | 1 | 1U RISER PCI-E (X8) TO PCI-E (X8) ROHS |
| Heatsink / Retention | SNK-P0046P | 1 | 1U PASSIVE CPU HS FOR INTEL LGA1156 |
| Power Supply | PWS-351-1H | 1 | 1U 350W MULTI OUTPUT 80PLUS GOLD PWS |
| Cable 4 | CBL-0155L | 1 | IDE 80-WIRE CABLE FOR DVD ROM, 60 CM FOR 811,PB FREE |
| Fan 1 | FAN-0059L4 | 2 | 10CM 4PIN PWM BLOWER FOR SC813, PBF |
| Drive Tray(s) | MCP-220-00003-01 | 2 | Black gen 1 hot-swap 3.5" HDD tray (square hole w/o logo) |
| Mounting Rails | CSE-PT8 | 1 | 810, 811 rails. Outer slides extendable length: 25 |
