Supermicroのサーバ：5017C-MF
1. Single socket H2 (LGA 1155) supports
Intel® Xeon® E3-1200 & v2 series,
2nd Gen Core i3 processors*
2. Intel® C202 PCH Chipset
3. 2x Internal 2.5"/3.5" HDDs
4. 1x PCI-E 3.0* x8 Full-height slot
5. Up to 32GB DDR3 ECC 1333MHz /
1600MHz* UDIMMs in 4 sockets
6. Intel® 82579LM and 82574L,
2x Gigabit Ethernet LAN ports
7. IPMI 2.0 on Dedicated LAN port
8. 6x SATA 2.0 with RAID 0, 1, 5, 10
9. 350W Gold Level Power Supply
10. 1x Slim DVD-ROM Drive (optional)
11. Disk-on-module (DOM) power
connector
| 製品仕様 | |
|---|---|
| Product SKUs | |
| SYS-5017C-MF | SuperServer 5017C-MF (Black) |
| マザーボード | |
| Motherboard | Super X9SCL-F |
| プロセッサ/キャッシュ | |
| CPU | Intel® Xeon® processor E3-1200 & v2 series, Intel® 2nd Gen Core i3 processors * Socket H2 (LGA 1155) |
| メモリ | |
| Memory Capacity | 4x 240-pin DDR3 DIMM sockets Supports up to 32 GB DDR3 ECC Un-Buffered memory (UDIMM) |
| Memory Type | 1600*/1333/1066/800MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs |
| DIMM Sizes | 8GB, 4GB, 2GB, 1GB |
| Memory Voltage | 1.5 V |
| Error Detection | Corrects single-bit errors Detects double-bit errors (using ECC memory) |
| オンボードデバイス | |
| Chipset | Intel® C202 PCH chipset |
| SATA | 6x SATA 2.0 (3Gbps) w/ RAID 0, 1, 5, 10 |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Nuvoton WPCM450 BMC |
| Network Controllers | Intel® 82579LM and Intel® 82574L, 2x Gigabit Ethernet LAN ports Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output 1x Realtek RTL8201N PHY (dedicated IPMI) |
| VGA | Nuvoton WPCM450RA0BX |
| Super I/O | Nuvoton NCT6776F |
| Clock Generator | CK505 |
| 標準インターフェース | |
| Serial ATA | 6 SATA ports 6 SATA hard drives supported |
| LAN | 2x RJ45 LAN ports 1x RJ45 Dedicated IPMI LAN port |
| USB | 2x USB rear ports 1x USB Type-A 6x USB ports via header Total 9 USB 2.0 Compliant |
| VGA | 1x VGA port |
| Keyboard / Mouse | PS/2 keyboard and mouse ports |
| Serial Port / Header | 1x Fast UART 16550 serial port 1x internal header |
| シャーシ | |
| Form Factor | 1U Rackmount |
| Model | CSE-512F-350B |
| 外形寸法/重量 | |
| Height | 1.7" (43mm) |
| Width | 17.2" (437mm) |
| Depth | 14.5" (369mm) |
| Gross Weight | 38 lbs (16.5kg) |
| Available Colors | Black |
| フロントパネル | |
| Buttons | Power On/Off button System Reset button |
| LEDs | Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED |
| 拡張スロット | |
| PCI-E | 1x PCI-E 2.0 x8 slot |
| ドライブベイ | |
| Internal HDDs | 2x 3.5" internal HDDs |
| Peripheral Drives | |
| DVD-ROM | Slim DVD-ROM Drive (optional) |
| バックプレーン | |
| Backplane | SAS/SATA HDD Backplane(SAS support requires optional SAS controller) |
| 冷却機構 | |
| Fans | 2x 4cm 4-pin PWM Fans |
| 電源 | |
| Power Supply | 350W AC power supply w/ PFC |
| AC Voltage | 100-240 V, 50-60 Hz, 4.2-1.8 Amp |
| +5V | 18 Amp |
| +5V standby | 3 Amp |
| +12V | 29 Amp |
| +3.3V | 15 Amp |
| Certification | 80 PLUS Gold Certified[ Test Report ] |
| BIOS | |
| BIOS Type | 8Mb SPI Flash EEPROM with AMI BIOS |
| BIOS Features | DMI 2.3 PCI 2.3 ACPI 1.0 / 2.0 USB Keyboard support SMBIOS 2.3 |
| 動作環境/コンプライアンス | |
| RoHS | RoHS Compliant |
| Environmental Spec. | Operating Temperature: 10° to 35°C (50° to 95°F) Non-operating Temperature: -40° to 70°C (-40° to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5 to 95% (non-condensing) |
| 拡張スロット | |
| PCI-Express | 1x PCI-E 3.0* x8 Full-height slot |
| パーツリスト(付属品) | |||
|---|---|---|---|
| 型番 | 数量 | 内容 | |
| パーツリスト | |||
| Motherboard / Chassis | MBD-X9SCL-F | 1 | Super X9SCL-F Motherboard |
| Motherboard / Chassis | CSE-512F-350B | 1 | 1U Chassis |
| Cable 1 | CBL-0058L | 1 | 17CM, SATA CABLE, PB FREE |
| Cable 2 | CBL-0061L | 1 | 35CM, SATA CABLE, PB FREE |
| CD | CDR-X9-UP | 1 | Driver CD for X9-UP series motherboard |
| Riser Card | CSE-RR1U-E8 | 1 | 1U RISER PCI-E (X8) TO PCI-E (X8) ROHS |
| Heatsink / Retention | SNK-P0046P | 1 | 1U PASSIVE CPU HS FOR INTEL LGA1156 |
| Power Supply | PWS-351-1H | 1 | 1U 350W MULTI OUTPUT 80PLUS GOLD PWS |
| Cable 3 | CBL-0156L | 1 | Front ctrl cable Round 16pin to 16pin, 40cm, PBF |
| Cable 4 | CBL-0260L | 1 | US power cord 18AWG 6ft, PBF (default for low watt) |
| Cable 5 | CBL-0261L | 1 | 40CM 7PIN SATA CABLE S-RA for SC512,512L, PBF |
| Cable 6 | CBL-0262L | 1 | 4PIN TO 1xSATA(RA)+1x4PIN(RA)+1xFPD PWS EXT. CBL |
| Fan 1 | FAN-0087L4 | 2 | 40x56,4 Pin PWM Fan |
