| Form Factor |
267 x 305 mm |
| CPU |
2 x Intel Xeon 5500/ 5600 Series (LGA1366) |
| Chipset |
Intel 5500 + ICH10R |
| Memory |
6 x 3 chanels DDR3 slots
RDIMM or ECC UDIMM
1333/ 1066MHz |
| LAN |
2 x GbE controllers (Intel 82574L) |
| Video |
ASPEED 1300 128MB DDR3 |
| SATA |
6 x SATA 3Gbp/s |
| RAID |
Intel SW RAID 0/ 1/ 5/ 10
optional 8-ports SAS HW RAID card
optional 8-ports SAS SW RAID card |
| Expansion Slots |
1 x PCIe 2.0 x16
2 x PCIe 2.0 x4 (x8 mechanical)
1 x PCIe x1
1 x PCI |
| Rear I/O |
1 x VGA
1 x COM
4 x USB 2.0
2 x RJ45 |
| Board Management |
HW Monitor |
